AEG MODICON B875-111模拟输入模块

AEG MODICON B875-111模拟输入模块

1.产 品 资 料 介 绍：

1. AEG MODICON B875-111 是 Modicon 800 系列中主打高精度的模拟输入模块。
2. 支持 8 个差分或 16 个单端输入配置，可由用户按需灵活选择。
3. 涵盖 5 种电压输入范围，适配 0 - 5V、-10 - +10V 等多类电压信号采集。
4. 兼容 3 种电流输入范围，能适配 4 - 20mA 等工业常用传感电流信号。
5. 具备 ±0.1% 的测量精度与 14 位分辨率，保障模拟信号采集的准确性。
6. 8 路输入更新率达 10ms，16 路输入为 20ms，满足实时信号采集需求。
7. 电压模式输入阻抗超 10MΩ，电流模式为 250Ω，减少信号采集干扰。
8. 具备 1500VAC 通道与模块间隔离，提升系统电气安全防护能力。
9. 内置单极低通滤波器，48Hz 截止频率可过滤高频杂波信号。
10. 支持四种输出格式选择，可通过 DIP 开关完成便捷配置。
11. 适配 Modicon 984 系列 PLC，可通过 Unity Pro 软件编程配置。
12. 工作温度范围 - 20℃至 + 55℃，适配多数严苛工业温环境。
13. 模块化结构设计，能与同系列 I/O 模块组合，便于系统拓展与维护。
14. 具备 120V 有效值输入保护，可抵御电压尖峰对模块的损坏。
15. AEG MODICON B875 - 111 为工业温压、流量等信号采集提供稳定转换方案。

AEG MODICON B875-111模拟输入模块 英文资料：

AEG MODICON B875-111 is a high-precision analog input module in the Modicon 800 series.

Supports 8 differential or 16 single ended input configurations, allowing users to flexibly choose according to their needs.

Covering 5 voltage input ranges, suitable for collecting various voltage signals such as 0-5V, -10-+10V, etc.

Compatible with 3 current input ranges, able to adapt to commonly used industrial sensing current signals such as 4-20mA.

With a measurement accuracy of ± 0.1% and a 14 bit resolution, it ensures the accuracy of analog signal acquisition.

The ｕｐｄａｔｅ rate of 8 inputs reaches 10ms, and the ｕｐｄａｔｅ rate of 16 inputs is 20ms, meeting the real-time signal acquisition requirements.

The voltage mode input impedance exceeds 10M Ω, and the current mode is 250 Ω, reducing signal acquisition interference.

Equipped with 1500VAC channel and module isolation to enhance the electrical safety protection capability of the system.

Built in single pole low-pass filter, with a cutoff frequency of 48Hz, can filter high-frequency clutter signals.

Supports four output format options and can be conveniently configured through DIP switches.

Compatible with Modicon 984 series PLC, can be programmed and configured through Unity Pro software.

Working temperature range -20 ℃ to+55 ℃, suitable for most harsh industrial temperature environments.

Modular structure design, able to be combined with I/O modules of the same series, facilitating system expansion and maintenance.

Equipped with 120V effective value input protection, it can resist damage to the module caused by voltage spikes.

AEG MODICON B875-111 provides a stable conversion solution for industrial temperature, pressure, flow and other signal acquisition.

AEG MODICON B875-111模拟输入模块 产品展示
