1.产 品 资 料 介 绍：
- MDFKARS090-22 采用永磁同步设计，额定功率 0.75kW，额定扭矩 2.4N・m，3000rpm 额定转速，适配中功率精密驱动场景
- 搭载 2500p/r 高分辨率编码器，定位精度达 ±0.01°，闭环控制保障设备轨迹控制一致性与重复定位精度
- 适配三相 AC 220V 标准供电，电压波动耐受 ±10%，应对工业电网波动，地域与场景适应性广
- MDFKARS090-22 防护等级达 IP65，金属密封外壳防尘防水溅，可直接部署于机械加工、自动化生产线等多粉尘工况
- 兼容 Modbus、EtherCAT 等主流工业通信协议，与 PLC、伺服驱动器联动响应迅速，数据传输延迟≤1ms
- 工作温度覆盖 - 10℃~60℃，耐受湿度≤90%（无凝露），搭配 F 级绝缘设计，适配高低温波动工业环境
- MDFKARS090-22 具备 150% 额定扭矩过载 60 秒能力，内置过流、过热、堵转多重保护，保障电机与负载安全
- 低速运行平稳无抖动，力矩波动≤±5%，满足数控机床低速进给、精密定位等高精度工艺需求
- 支持位置 / 速度 / 转矩三模式切换，可通过参数自由配置，适配不同工艺控制需求
- MDFKARS090-22 机身采用高强度铝合金材质，重量轻且散热性能优异，连续运行温升≤80K，延长使用寿命
- 标准法兰安装设计，适配各类自动化设备安装布局，搭配锥形花键轴，连接牢固传动精度高
- 内置电磁制动功能，制动响应时间≤20ms，断电后快速锁轴，防止负载滑行，提升运行安全性
- MDFKARS090-22 广泛应用于数控铣床、加工中心、自动化机械手、包装机械等精密制造设备
- 深度兼容主流伺服驱动器，无需额外适配模块，集成成本低，调试便捷高效
- 沿用标准化安装尺寸与接线接口，新旧设备替换时无需改动机械结构与布线，缩短停机维护时间
MDFKARS090-22伺服电机 英文资料：
MDFKARS090-22 adopts a permanent magnet synchronous design, with a rated power of 0.75kW, a rated torque of 2.4N · m, and a rated speed of 3000rpm, suitable for medium power precision drive scenarios
Equipped with a 2500p/r high-resolution encoder, the positioning accuracy reaches ± 0.01 °, and closed-loop control ensures the consistency of equipment trajectory control and repeated positioning accuracy
Suitable for three-phase AC 220V standard power supply, with a voltage fluctuation tolerance of ± 10%, to cope with industrial power grid fluctuations, and has wide adaptability to different regions and scenarios
MDFKARS090-22 has a protection level of IP65 and a metal sealed shell that is dustproof, waterproof, and splash proof. It can be directly deployed in multi dust working conditions such as mechanical processing and automated production lines
Compatible with mainstream industrial communication protocols such as Modbus and EtherCAT, it responds quickly in conjunction with PLCs and servo drives, with a data transmission delay of ≤ 1ms
Working temperature coverage -10 ℃~60 ℃, humidity tolerance ≤ 90% (no condensation), equipped with F-class insulation design, suitable for high and low temperature fluctuation industrial environment
MDFKARS090-22 has the ability to withstand 150% rated torque overload for 60 seconds, with built-in multiple protections for overcurrent, overheating, and locked rotor, ensuring the safety of the motor and load
Smooth and vibration free low-speed operation, torque fluctuation of ≤± 5%, meeting high-precision process requirements such as low-speed feed and precision positioning for CNC machine tools
Support position/speed/torque three mode switching, which can be freely configured through parameters to adapt to different process control requirements
The MDFKARS090-22 body is made of high-strength aluminum alloy material, which is lightweight and has excellent heat dissipation performance. The continuous operating temperature rise is ≤ 80K, extending the service life
Standard flange installation design, suitable for installation layout of various automation equipment, matched with tapered spline shaft, firmly connected, high transmission accuracy
Built in electromagnetic braking function, braking response time ≤ 20ms, quickly locks the axle after power failure to prevent load sliding and improve operational safety
MDFKARS090-22 is widely used in precision manufacturing equipment such as CNC milling machines, machining centers, automated robotic arms, packaging machinery, etc
Deeply compatible with mainstream servo drives, no additional adaptation module required, low integration cost, convenient and efficient debugging
Using standardized installation dimensions and wiring interfaces, there is no need to modify the mechanical structure and wiring when replacing old and new equipment, reducing downtime for maintenance
MDFKARS090-22伺服电机 产品展示
