5AP1120.0702-C控制面板

发布时间：2025-12-09人气：

5AP1120.0702-C控制面板

1.产品资料介绍：

5AP1120.0702-C 控制面板：贝加莱 AP1000 系列工业交互核心！

7 英寸 WVGA 彩色 TFT 屏，800×480 分辨率 + 1670 万色，显示细腻清晰～

模拟电阻式单点触摸，5AP1120.0702-C 操作响应精准无延迟！

前端 IP65 防护 + 后端 IP20 防护，防尘防水适配恶劣工业环境。

80-500 cd/m² 可调 LED 背光，5AP1120.0702-C 强光下可视性拉满！

50000 小时背光寿命，聚酯材质面板 + 3mm 内置垫圈，耐用性优异。

600:1 高对比度，5AP1120.0702-C 数据显示清晰无眩光！

24V DC 标准供电，符合工业供电规范，运行稳定可靠。

兼容 RS-485 + 以太网接口，5AP1120.0702-C 数据传输灵活高效！

适配 PPC2100/PPC2200 系统，兼容 5PP520.0702-00 扩展模块。

0~60℃宽工作温度 + 90% RH 无凝结，5AP1120.0702-C 极端工况适配！

紧凑型设计仅重 900g，支持控制柜安装，节省空间部署灵活。

符合 EN 61131-2 污染等级 2 标准，5AP1120.0702-C 环保无危害！

广泛应用于制造业、石油化工、电网电厂等工业自动化场景。

选择 5AP1120.0702-C，解锁稳定、耐用、高适配的工业交互解决方案！

5AP1120.0702-C控制面板 英文资料：

5AP1120.0702-C Control Panel: Beijiale AP1000 Series Industrial Interaction Core!

7-inch WVGA color TFT screen, 800 × 480 resolution+16.7 million colors, displaying delicate and clear~

Simulate resistive single point touch, 5AP1120.0702-C operation response is precise without delay!

Front end IP65 protection+back-end IP20 protection, dustproof and waterproof, suitable for harsh industrial environments.

80-500 cd/m ² adjustable LED backlight, 5AP1120.0702-C full visibility under strong light!

50000 hours backlight life, polyester material panel+3mm built-in gasket, excellent durability.

600:1 high contrast, 5AP1120.0702-C data display clear and glare free!

24V DC standard power supply, in compliance with industrial power supply standards, stable and reliable operation.

Compatible with RS-485+Ethernet interface, 5AP1120.0702-C data transmission is flexible and efficient!

Compatible with PPC2100/PPC2200 systems, compatible with 5PP520.0702-00 expansion module.

0~60 ℃ wide working temperature+90% RH without condensation, suitable for extreme working conditions with 5AP1120.0702-C!

The compact design weighs only 900g and supports control cabinet installation, saving space and allowing for flexible deployment.

Compliant with EN 61131-2 pollution level 2 standard, 5AP1120.0702-C environmentally friendly and non hazardous!

Widely used in industrial automation scenarios such as manufacturing, petrochemicals, power grids, and power plants.

Choose 5AP1120.0702-C to unlock a stable, durable, and highly adaptable industrial interaction solution!

5AP1120.0702-C控制面板 产品展示

b_r_5ap1120_0702-c_01_rev_d0_panel_pc_2200_-_6_months_warranty (1).jpg
