1.产 品 资 料 介 绍：
- SRM50-HWA0-K22 每圈 1024 正余弦信号，细分后达 32768 个绝对位置，定位精度达 ±52″
- 支持 4096 圈多圈测量，总步数 134217728 步，满足长行程精密控制需求
- 搭载 HIPERFACE® 接口，可同步监控速度、位置与换向，信号传输精准无偏差
- SRM50-HWA0-K22 工作转速可达 6000rpm，角加速度≤200000rad/s²，高速响应敏捷
- 防护等级达 IP65，防尘防水防溅，适配潮湿多尘工业现场环境
- 供电电压 7-12VDC，建议 8VDC 供电，电流消耗仅 80mA，低功耗节能突出
- 采用 10mm 实心轴设计，径向负荷 40N、轴向负荷 20N，机械承载能力强劲
- SRM50-HWA0-K22 工作温度范围 - 30~+85℃，宽温适配多地域复杂工况
- 具备电子铭牌功能，支持编码器与电机型号识别，参数管理更便捷
- 抗冲击能力达 100g、抗振动 20g（10-2000Hz），复杂环境运行稳定
- 配备 M23 12 针径向公接头，接线可靠，支持长距离电缆传输
- SRM50-HWA0-K22 内置 1792Byte 存储空间，可存储电机信息与自定义参数
- 符合 SIL2/PLd 安全认证与 RoHS 标准，合规性适配全球工业应用
- 转动惯量仅 25gcm²，运行转矩 1Ncm，启停无冲击，保护电机部件
- 法兰安装设计，重量≤0.2kg，体积紧凑，节省设备安装空间
SRM50-HWA0-K22 伺服电机 英文资料：
SRM50-HWA0-K22 generates 1024 sine and cosine signals per circle, resulting in 32768 absolute positions after subdivision, with a positioning accuracy of ± 52 ″
Supports 4096 cycles of multi cycle measurement, with a total of 134217728 steps, meeting the requirements of long-distance precision control
Equipped with HIPERFACE ® Interface, capable of synchronously monitoring speed, position, and direction change, with precise and error free signal transmission
The working speed of SRM50-HWA0-K22 can reach 6000rpm, with an angular acceleration of ≤ 200000 rad/s ² and agile high-speed response
Protection level up to IP65, dustproof, waterproof, splash proof, suitable for humid and dusty industrial site environments
The power supply voltage is 7-12VDC, and it is recommended to supply 8VDC. The current consumption is only 80mA, and the low power consumption and energy saving are outstanding
Adopting a 10mm solid shaft design, with a radial load of 40N and an axial load of 20N, the mechanical load-bearing capacity is strong
SRM50-HWA0-K22 operates within a temperature range of -30~+85 ℃, with a wide temperature range suitable for complex working conditions in multiple regions
Equipped with electronic nameplate function, supporting encoder and motor model recognition, parameter management is more convenient
The impact resistance reaches 100g, the vibration resistance is 20g (10-2000Hz), and the operation is stable in complex environments
Equipped with M23 12 pin radial male connector, reliable wiring, supports long-distance cable transmission
SRM50-HWA0-K22 has built-in 1792Byte storage space, which can store motor information and custom parameters
Compliant with SIL2/PLd safety certification and RoHS standards, compliant for global industrial applications
The moment of inertia is only 25gcm ², the operating torque is 1Ncm, there is no impact during start stop, and the motor components are protected
Flange installation design, weight ≤ 0.2kg, compact volume, saving equipment installation space
SRM50-HWA0-K22 伺服电机 产品展示
产品视频
