1.产 品 资 料 介 绍：
- SICK SRM50-FPA0-K21 是 SRM50 系列伺服反馈编码器，专为高动态性能伺服电机设计，适配机械制造、电子光伏等行业。
- 该型号采用 HIPERFACE® 通讯接口，与 SRM50-HPA0-K21、SRS50-HPA0-K21 共享核心通讯协议，兼容性强。
- 供电电压范围 7-12V DC，推荐 8V DC 供电，功耗仅 80mA，与 SRS50-HFA0-K21 的电气参数保持一致。
- 测量精度出色，系统精度达 ±52″，积分非线性 Typ.±45″，媲美同系列 SRM50-FFA0-S21 的高精度表现。
- 每圈正弦 / 余弦周期 1024，12 位插值后测量步距 0.3″，满足精密位置检测需求。
- 机械结构采用半中空轴设计，重量≤0.2kg，转动惯量 50gcm²，安装灵活，与 SRS50-HPA0-K21 尺寸规格兼容。
- 工作转速可达 3000min⁻¹（绝对位置可靠输出），最高耐受 6000min⁻¹ 转速，适配高转速伺服系统。
- 防护等级 IP65，能在 - 40℃~+85℃环境中稳定工作，抗冲击 100g、抗振动 20g，适应恶劣工业场景。
- 支持 128Byte 可用记忆库，可存储关键运行参数，与 SRM50-HPA0-K21 的存储容量相同。
- 连接类型为 10 针径向公接头，可搭配 DOS-MS10-G、DOL-MS10-G03MMA3 等专用电缆配件。
- 绝对式编码类型，上电即读位置，无需回零操作，提升系统启动效率，与 SRS50-HFA0-K21 功能一致。
- MTTF 达 235 年，可靠性突出，适合长期连续运行的工业设备。
- 适配机器人关节驱动、数控机床等场景，可与 SRS/SRM50 系列其他型号互换使用，降低替换成本。
- 电磁兼容性符合 EN 610068 标准，减少工业环境电磁干扰对测量的影响。
- 可通过 PGT-11-S LAN 编程工具进行参数配置，与同系列编码器共用配置系统，操作便捷。
SRM50-FPA0-K21编码器 英文资料：
SICK SRM50-FPA0-K21 is an SRM50 series servo feedback encoder designed specifically for high dynamic performance servo motors, suitable for industries such as mechanical manufacturing and electronic photovoltaics.
This model uses HIPERFACE ® Communication interface, sharing core communication protocol with SRM50-HPA0-K21 and SRS50-HPA0-K21, with strong compatibility.
The power supply voltage range is 7-12V DC, with a recommended 8V DC power supply and a power consumption of only 80mA, consistent with the electrical parameters of SRS50-HFA0-K21.
Excellent measurement accuracy, with a system precision of ± 52 "and an integral nonlinear Typ. ± 45", comparable to the high-precision performance of the same series SRM50-FFA0-S21.
Each sine/cosine cycle is 1024, and after 12 bit interpolation, the measurement step is 0.3 inches, which meets the requirements of precise position detection.
The mechanical structure adopts a semi hollow shaft design, with a weight of ≤ 0.2kg and a moment of inertia of 50gcm ². It is flexible to install and compatible with the size specifications of SRS50-HPA0-K21.
The working speed can reach 3000min ⁻¹ (reliable absolute position output), with a maximum tolerance of 6000min ⁻¹ speed, suitable for high-speed servo systems.
Protection level IP65, capable of stable operation in environments ranging from -40 ℃ to+85 ℃, resistant to impact of 100g and vibration of 20g, suitable for harsh industrial scenarios.
Supports a 128Byte available memory bank that can store critical operational parameters, with the same storage capacity as SRM50-HPA0-K21.
The connection type is a 10 pin radial male connector, which can be paired with specialized cable accessories such as DOS-MS10-G and DOL-MS10-G03MMA3.
Absolute encoding type, read position immediately upon power on, no need for zeroing operation, improves system startup efficiency, consistent with the function of SRS50-HFA0-K21.
MTTF has been in use for 235 years, with outstanding reliability and suitable for long-term continuous operation of industrial equipment.
Suitable for scenarios such as robot joint drive and CNC machine tools, it can be interchanged with other models of the SRS/SRM50 series to reduce replacement costs.
Electromagnetic compatibility complies with EN 610068 standard, reducing the impact of electromagnetic interference in industrial environments on measurements.
Parameter configuration can be done through the PGT-11-S LAN programming tool, which shares the configuration system with encoders of the same series and is easy to operate.
SRM50-FPA0-K21编码器 产品展示
