1.产 品 资 料 介 绍：
- 845H-NXC777303 采用增量式光学检测设计，支持 A/B 双通道 + 零位索引，信号相位差 90°±22°，定位反馈精准
- 分辨率最高可达 5000PPR，脉冲对称性 50%±10%，满足中高精度运动控制需求
- 供电电压兼容 8-24VDC 宽范围，最大电流 150mA，工业场景供电适配性强
- 845H-NXC777303 信号响应频率达 210kHz，适配最高 6000rpm 转速，高速追踪无延迟
- 防护等级达 IP66（NEMA 4/13），防尘防水防油污，适配恶劣工业现场环境
- 输出支持 PNP 电流源、NPN 电流沉等多模式，驱动能力均为 20mA，兼容多种控制系统
- 845H-NXC777303 轴径可选 6mm/10mm 等规格，径向负荷 178N、轴向负荷 89N，机械承载强劲
- 工作温度范围 - 25~90℃（存储）、0~60℃（运行），宽温适配多地域复杂工况
- 抗冲击能力达 50g（11ms 持续），抗振动 20g（4-2000Hz），复杂环境运行稳定
- 845H-NXC777303 转动惯量仅 15gcm²，启动转矩 2.5Ncm，运行无附加负荷
- 兼容罗克韦尔 PLC 与伺服驱动系统，信号传输抗干扰能力强，工业组网可靠
- 采用屏蔽电缆设计，需规范接地，符合国际电气规范，信号传输无失真
- 845H-NXC777303 重量约 0.91kg，法兰安装设计，适配多种设备安装布局
- 工作湿度耐受 98% 非凝结环境，潮湿工况下性能无衰减，稳定性突出
- 适配机床、输送设备、自动化产线等场景，与罗克韦尔自动化系统无缝兼容，集成成本低
845H-NXC777303编码器 英文资料：
845H-NXC777303 adopts an incremental optical detection design, supporting A/B dual channels and zero position indexing, with a signal phase difference of 90 °± 22 ° and precise positioning feedback
The resolution can reach up to 5000PPR, with pulse symmetry of 50% ± 10%, meeting the requirements of medium to high precision motion control
The power supply voltage is compatible with a wide range of 8-24VDC, with a maximum current of 150mA, and strong adaptability to industrial power supply scenarios
845H-NXC777303 signal response frequency reaches 210kHz, suitable for up to 6000rpm speed, high-speed tracking without delay
Protection level up to IP66 (NEMA 4/13), dustproof, waterproof, oil proof, suitable for harsh industrial site environments
Output supports multiple modes such as PNP current source and NPN current sink, with a driving capability of 20mA and compatibility with multiple control systems
845H-NXC777303 shaft diameter can be selected in specifications such as 6mm/10mm, with a radial load of 178N and an axial load of 89N, providing strong mechanical load-bearing capacity
Working temperature range -25~90 ℃ (storage), 0~60 ℃ (operation), wide temperature adaptability to complex working conditions in multiple regions
The impact resistance reaches 50g (11ms continuous), the vibration resistance is 20g (4-2000Hz), and the operation is stable in complex environments
845H-NXC777303 has a moment of inertia of only 15gcm ², a starting torque of 2.5Ncm, and operates without additional load
Compatible with Rockwell PLC and servo drive systems, with strong anti-interference ability in signal transmission and reliable industrial networking
Adopting shielded cable design, requiring standardized grounding, complying with international electrical standards, and ensuring distortion free signal transmission
845H-NXC777303 weighs approximately 0.91kg and is designed for flange installation, suitable for various equipment installation layouts
The working humidity can withstand 98% non condensing environment, and the performance does not deteriorate under humid conditions, with outstanding stability
Compatible with machine tools, conveying equipment, automated production lines, and other scenarios, seamlessly compatible with Rockwell Automation systems, with low integration costs
845H-NXC777303编码器 产品展示
