1.产 品 资 料 介 绍：
- A985GOT-TBA-EU 是三菱原装工业触摸屏，属于 A985GOT 系列高性能机型，核心性能稳定可靠，符合工业人机交互标准。
- 适配数控机床、自动化生产线、PLC 控制系统等场景，覆盖机械制造、电子加工、化工等多行业操作需求。
- 配备 TFT 彩色显示屏，分辨率达 800×600 像素，支持 65536 色显示，画面清晰细腻，操作可视化效果佳。
- 正面防护等级达 IP67F，完全防尘且能抵御短时间浸水，适配多尘、潮湿等恶劣工业工况。
- 触摸面板支持 100 万次以上操作寿命（操作用力≤0.98N），耐磨耐用，长期使用稳定性强。
- A985GOT-TBA-EU 支持最多 4 个视频窗口同时显示，可叠加显示且不影响画面完整性，适配多画面监控场景。
- 具备 SVGA 电脑屏幕捕捉功能，可直接显示 800×600 或 640×480 分辨率的 PC 画面，数据同步便捷。
- 工作电压适配 100-240VAC 或 24VDC，电压适应范围宽，可应对工业现场电压小幅波动。
- 显示角度优异，左右视角达 60°、上视角 40°、下视角 50°，多方位操作均能清晰观测。
- 内置 1MB 用户存储器（最大可扩展至 9MB），支持 JPEG 图像保存，数据存储容量充足。
- A985GOT-TBA-EU 配备晶体管输出接口（2 点，12/24VDC 0.1A），可直接对接外部执行元件。
- 耐温性能出色，运行环境温度 0-40℃、存储温度 - 20-60℃，适应工业常规温控场景。
- 抗电磁干扰能力强，符合 JIS B 3502、IEC 61131-2 标准，不受周边设备信号干扰。
- 绝缘电阻≥10MΩ，耐电压 AC1500V（AC 供电）/500V（DC 供电），电气安全性高。
- A985GOT-TBA-EU 支持背光亮度 8 档调节，可设置背光 OFF 屏幕保护，延长背光使用寿命（40000 小时 / 25℃）。
- 兼容三菱 Q 系列、FX 系列 PLC 及主流工业控制器，集成对接无需额外适配模块。
- 外部尺寸 312W×238H×49D，面板切割尺寸 302W×228H，安装便捷，适配标准面板布局。
- 原装正品保障，符合 UL/cUL 国际认证，现货供应充足，物流配送高效，维修替换便捷。
A985GOT-TBA-EU触摸屏 英文资料：
A985GOT-TBA-EU is a Mitsubishi original industrial touch screen, belonging to the A985GOT series of high-performance models, with stable and reliable core performance, in line with industrial human-computer interaction standards.
Suitable for scenarios such as CNC machine tools, automated production lines, PLC control systems, etc., covering the operational needs of multiple industries such as mechanical manufacturing, electronic processing, and chemical engineering.
Equipped with TFT color display screen, with a resolution of 800 × 600 pixels and support for 65536 color display, the image is clear and delicate, and the visual effect of operation is excellent.
The front protection level reaches IP67F, completely dustproof and able to withstand short-term immersion, suitable for harsh industrial conditions such as high dust and humidity.
The touch panel supports a lifespan of over 1 million operations (operating force ≤ 0.98N), is wear-resistant and durable, and has strong long-term stability.
A985GOT-TBA-EU supports up to 4 video windows to be displayed simultaneously, which can be overlaid without affecting the integrity of the image, and is suitable for multi screen monitoring scenarios.
Equipped with SVGA computer screen capture function, it can directly display PC images with resolutions of 800 × 600 or 640 × 480, and data synchronization is convenient.
The working voltage is suitable for 100-240VAC or 24VDC, with a wide voltage adaptation range, and can cope with small voltage fluctuations in industrial sites.
Excellent display angle, with a left and right viewing angle of 60 °, an up viewing angle of 40 °, and a down viewing angle of 50 °, allowing for clear observation in multiple directions.
Built in 1MB user memory (expandable up to 9MB), supports JPEG image saving, and has sufficient data storage capacity.
A985GOT-TBA-EU is equipped with a transistor output interface (2-point, 12/24VDC 0.1A), which can be directly connected to external actuators.
Excellent temperature resistance, operating environment temperature of 0-40 ℃, storage temperature of -20-60 ℃, suitable for industrial conventional temperature control scenarios.
Strong resistance to electromagnetic interference, in compliance with JIS B 3502 and IEC 61131-2 standards, and not affected by signal interference from surrounding devices.
Insulation resistance ≥ 10M Ω, withstand voltage AC1500V (AC power supply)/500V (DC power supply), high electrical safety.
A985GOT-TBA-EU supports 8-level adjustment of backlight brightness, and can set backlight OFF screen protection to extend backlight lifespan (40000 hours/25 ℃).
Compatible with Mitsubishi Q series, FX series PLCs and mainstream industrial controllers, integrated docking does not require additional adaptation modules.
The external dimensions are 312W × 238H × 49D, and the panel cutting dimensions are 302W × 228H. It is easy to install and compatible with standard panel layouts.
Original genuine product guarantee, compliant with UL/cUL international certification, sufficient stock supply, efficient logistics and distribution, convenient maintenance and replacement.
A985GOT-TBA-EU触摸屏 产品展示
产品视频
