810-800082-043电路板

810-800082-043电路板

1.产 品 资 料 介 绍：

810-800082-043电路板产品特点

- 采用工业级高稳定FR4基材，Tg值≥140℃，耐热性与机械承载能力优异

- 符合IPC-A-600G Class 2工业标准，保障批量生产的一致性与可靠性

- 支持RoHS环保规范，无铅化设计，适配绿色工业生产需求

- 最小线宽/线距可达0.1mm，布线密度高，适配精密元器件布局

- 采用无铅喷锡表面处理，焊接性能稳定，抗氧化能力强，使用寿命长

- 最小成品孔径0.2mm，支持高精度钻孔工艺，适配小型贴片元件安装

- 绝缘电阻≥1000MΩ，耐压性能优异，电气稳定性强，减少故障风险

- 工作温度范围-40~85℃，适应恶劣工业温区环境，抗温变能力突出

- 具备优异的尺寸稳定性，高温高湿环境下形变率低，保障连接精度

- 支持盲埋孔工艺，可实现复杂电路集成，有效节省板面空间

- 绿色阻焊+清晰丝印设计，元器件标识明确，便于后期维护与检修

- 经过电气性能全检与外观检测，无开路、短路等质量缺陷，良品率高

- 兼容Protel、Altium等主流设计软件格式，适配常规PCB设计与修改流程

- 可支持BGA等高密度封装元件焊接，满足高集成度电路功能需求

- 采用阻燃基材与阻焊剂，符合UL 94V-0阻燃标准，安全性能高

810-800082-043电路板 英文资料：

810-800082-043 Circuit Board Product Features

-Using industrial grade high stability FR4 substrate, Tg value ≥ 140 ℃, excellent heat resistance and mechanical bearing capacity

-Compliant with IPC-A-600G Class 2 industrial standards, ensuring consistency and reliability in mass production

-Support RoHS environmental regulations, lead-free design, and adapt to green industrial production needs

-The minimum line width/spacing can reach 0.1mm, with high wiring density, suitable for precision component layout

-Adopting lead-free tin spraying surface treatment, stable soldering performance, strong oxidation resistance, and long service life

-The minimum finished aperture is 0.2mm, supporting high-precision drilling technology and suitable for the installation of small surface mount components

-Insulation resistance ≥ 1000M Ω, excellent withstand voltage performance, strong electrical stability, reducing the risk of faults

-The working temperature range is -40~85 ℃, suitable for harsh industrial temperature zones, and has outstanding resistance to temperature changes

-Excellent dimensional stability, low deformation rate in high temperature and high humidity environments, ensuring connection accuracy

-Support blind buried hole technology, which can achieve complex circuit integration and effectively save board space

-Green solder mask+clear silk screen design, clear component identification, easy to maintain and repair in the later stage

-After full electrical performance inspection and appearance inspection, there are no quality defects such as open circuit or short circuit, and the yield rate is high

-Compatible with mainstream design software formats such as Protel and Altium, suitable for conventional PCB design and modification processes

-Can support soldering of high-density packaging components such as BGA, meeting the functional requirements of highly integrated circuits

-Using flame-retardant substrate and solder resist, in compliance with UL 94V-0 flame retardant standard, with high safety performance

810-800082-043电路板 产品展示
