AFP87432输入/输出端子板

AFP87432输入/输出端子板

1.产 品 资 料 介 绍：

KSQ331E1同步继电器极简说明

一、产品概述

KSQ331E1同步继电器（Megacon生产，ANSI 25类），核心用于发电机与电网、两台发电机间的同步检测，当电压、频率、相位参数达标且稳定设定时长后，输出合闸允许信号，避免非同步并网损坏设备，适配工业配电及中小型发电机组并网场景。

二、核心参数

- 电源：辅助电压200/240V AC（50/60Hz，允许±10%波动），输入电压多规格可选；性能：频率范围45-65Hz，相位/电压误差均可调，动作延时0-500ms；安装：支持导轨或插座安装，适配工业控制箱布局。

三、工作原理

基于电磁力矩平衡原理工作，实时检测两侧电源参数，达标且稳定至设定延时后内部触点闭合。仅具备同步检查功能，无自动同步及合闸延时补偿能力，配备旋转LED指示灯，可直观观察同步状态。

四、安装与调试要点

- 安装需远离粉尘、强电磁干扰源，多台相邻安装预留≥5mm间隙，高低压线路分开布线；调试前务必断电，检查外观与绝缘后，模拟电源参数测试功能，接入额定负载验证运行稳定性。

五、安全维护与故障排除

- 操作全程需断电并做好静电防护，定期巡检清洁、校准参数；常见故障：电压误差灯常亮查电压与线路，触点不动作查延时/线圈电压，过热异响查安装间隙与负载。

AFP87432输入/输出端子板 英文资料：

Brief Description of KSQ331E1 Synchronous Relay

1、 Product Overview

KSQ331E1 synchronous relay (produced by Megacon, ANSI Class 25) is used for synchronous detection between generators and the power grid, as well as between two generators. When the voltage, frequency, and phase parameters meet the standard and are stably set for a certain period of time, it outputs a closing permission signal to avoid equipment damage caused by asynchronous grid connection, and is suitable for industrial distribution and small and medium-sized generator grid connection scenarios.

2、 Core parameters

-Power supply: Auxiliary voltage 200/240V AC (50/60Hz, allowing ± 10% fluctuation), input voltage with multiple specifications to choose from; Performance: Frequency range of 45-65Hz, adjustable phase/voltage error, action delay of 0-500ms; Installation: Supports rail or socket installation, compatible with industrial control box layout.

3、 Working principle

Based on the principle of electromagnetic torque balance, real-time detection of power parameters on both sides, reaching the standard and stabilizing until the set delay, the internal contacts are closed. It only has synchronization check function, without automatic synchronization and closing delay compensation capability. It is equipped with a rotating LED indicator light, which can intuitively observe the synchronization status.

4、 Key points for installation and debugging

-Installation should be kept away from dust and strong electromagnetic interference sources. Multiple adjacent installations should reserve a gap of ≥ 5mm, and high and low voltage lines should be wired separately; Before debugging, it is necessary to turn off the power, check the appearance and insulation, simulate the power supply parameters to test the function, and connect to the rated load to verify the stability of operation.

5、 Safety maintenance and troubleshooting

-Power off and electrostatic protection should be implemented throughout the operation, and regular inspections, cleaning, and parameter calibration should be carried out; Common faults: The voltage error light is always on to check the voltage and circuit, the contact does not move to check the delay/coil voltage, overheating and abnormal noise to check the installation gap and load.
