1.产 品 资 料 介 绍：
2-3-0500-178印刷电路板产品特点及说明
一、产品概述与核心特点
2-3-0500-178为工业级PCB，适配自动化、精密仪器领域，核心特点：FR-4基材+加厚铜箔，散热导电佳；多层结构，机械强度高；工艺精良，阻抗精准、抗干扰强，保障信号稳定传输。
二、核心参数
- 基材工艺：FR-4基材，铜箔≥1盎司，支持多层布线，绝缘性优异。
- 性能：阻抗精度±5%，耐焊性280-360℃，符合工业抗干扰标准。
- 安装：兼容内置固定，公差精准，适配精密元器件装配。
三、工作原理
通过精准线路布局实现元器件信号与能量传输，依托优质基材快速散热，抗干扰、耐环境，防止短路故障，保障电路系统稳定运行。
四、安装与调试要点
- 安装：保持板面清洁，严控焊接温时，轻拿轻放避免线路损伤。
- 调试：检测焊点、导通性及阻抗匹配度，确保符合运行要求。
五、安全维护与故障排除
- 安全：佩戴防静电手环，避免接触腐蚀性溶剂。
- 维护：定期清洁板面、巡检焊点与温升。
- 故障：信号异常查阻抗/干扰，短路查焊点/绝缘，发热查散热/线路。
2-3-0500-178印刷电路板 英文资料：
2-3-0500-178 Characteristics and Description of Printed Circuit Board Products
1、 Product Overview and Core Features
2-3-0500-178 is an industrial grade PCB suitable for automation and precision instrument fields. Its core features include FR-4 substrate and thickened copper foil, which provide excellent heat dissipation and conductivity; Multi layer structure with high mechanical strength; Exquisite craftsmanship, precise impedance, strong anti-interference, ensuring stable signal transmission.
2、 Core parameters
-Substrate technology: FR-4 substrate, copper foil ≥ 1 ounce, supports multi-layer wiring, excellent insulation.
-Performance: Impedance accuracy ± 5%, solder resistance 280-360 ℃, in compliance with industrial anti-interference standards.
-Installation: Compatible with built-in fixation, precise tolerance, suitable for precision component assembly.
3、 Working principle
By precise circuit layout, component signals and energy transmission are achieved, relying on high-quality substrates for rapid heat dissipation, anti-interference, environmental resistance, and prevention of short circuit faults, ensuring stable operation of the circuit system.
4、 Key points for installation and debugging
-Installation: Keep the board clean, strictly control the welding temperature, and handle gently to avoid damage to the circuit.
-Debugging: Check solder joints, conductivity, and impedance matching to ensure compliance with operational requirements.
5、 Safety maintenance and troubleshooting
-Safety: Wear anti-static wristbands and avoid contact with corrosive solvents.
-Maintenance: Regularly clean the board surface, inspect solder joints and temperature rise.
-Fault: Check impedance/interference for abnormal signal, check solder joints/insulation for short circuit, check heat dissipation/circuit for heating.
2-3-0500-178印刷电路板 产品展示
