KSTE-KS-KR-2K印刷电路板

KSTE-KS-KR-2K印刷电路板

1.产 品 资 料 介 绍：

KSTE-KS-KR-2K是Schleicher品牌旗下的工业级印刷电路板（PCB），作为工控设备核心备件，主打高可靠性与精准信号传输，适配严苛工业场景的电路控制需求，核心特点及应用领域如下：

核心产品特点

高精度工艺，性能稳定：采用精密线路设计，最小线宽≥0。2mm，内层焊盘≥0。5mm、外层焊盘≥0。8mm，孔径公差控制在0。05mm内，确保信号传输精准无干扰，抗点击强度达100万次以上，适配长期高频工况。

工业级材质，耐候性佳：选用环氧树脂（EP）基材与玻纤布基增强材料，阻燃等级达V0级，具备优异的绝缘性能与抗老化能力。适配宽温工作环境，可耐受工业场景的温湿度波动与电磁干扰，稳定性突出。

优化结构设计，导通可靠：采用通孔金属化工艺，孔壁覆盖率高，导通电阻低，确保大电流传输与散热效率，避免因发热导致的性能衰减。双面线路布局，平衡设计复杂度与成本，适配多组件集成安装需求。

工控适配，通用性强：作为标准工控备件，可与Schleicher系列工控设备及施耐德电气相关系统无缝适配，机械接口与电气参数精准匹配，便于设备维修更换与升级改造，降低运维成本。

核心应用领域

主要应用于船舶半导体工控设备、工业自动化控制系统、精密测控仪器等场景，作为核心电路载体，支撑设备信号处理、指令传输与动力控制，适配船舶、冶金、化工等严苛工业领域的设备运行需求。

KSTE-KS-KR-2K印刷电路板 英文资料：

KSTE-KS-KR-2K is an industrial grade printed circuit board (PCB) under the Schleicher brand. As a core spare part for industrial control equipment, it focuses on high reliability and precise signal transmission, adapting to the circuit control requirements of harsh industrial scenarios. Its core features and application areas are as follows:

Core product features

High precision process, stable performance: adopting precision circuit design, minimum line width ≥ 0. 2mm， Inner pad ≥ 0. 5mm、 Outer solder pads ≥ 0. 8mm， The aperture tolerance is controlled at 0. Within 0.5mm, ensure accurate signal transmission without interference, with anti click strength of over 1 million times, suitable for long-term high-frequency working conditions.

Industrial grade material, good weather resistance: epoxy resin (EP) base material and glass fiber cloth based reinforcement material are selected, with a flame retardant grade of V0, excellent insulation performance and anti-aging capability. Suitable for a wide temperature working environment, able to withstand temperature and humidity fluctuations and electromagnetic interference in industrial scenarios, with outstanding stability.

Optimized structural design, reliable conductivity: Adopting through-hole metallization technology, the hole wall coverage is high, the conductivity resistance is low, ensuring high current transmission and heat dissipation efficiency, and avoiding performance degradation caused by heat generation. Double sided circuit layout, balancing design complexity and cost, suitable for multi component integrated installation requirements.

Industrial control adaptation, strong universality: As a standard industrial control spare part, it can seamlessly adapt to Schleicher series industrial control equipment and Schneider Electric related systems, with precise matching of mechanical interfaces and electrical parameters, facilitating equipment maintenance, replacement, and upgrading, reducing operation and maintenance costs.

Core application areas

Mainly used in ship semiconductor industrial control equipment, industrial automation control systems, precision measurement and control instruments and other scenarios, as the core circuit carrier, supporting equipment signal processing, instruction transmission and power control, and adapting to the operational requirements of harsh industrial fields such as ships, metallurgy, and chemical engineering.
