1.产 品 资 料 介 绍：
ME-MAX/NEF/QUINT20A是一款工业级接口过滤器，专为QUINT系列电源及工业设备接口设计，核心实现电磁干扰过滤与信号净化，兼具高适配性与可靠防护，是工业接口稳定性保障的关键组件，核心特点及应用领域如下：
核心产品特点
高效滤波，信号净化：集成GDT+MOV协同浪涌防护电路，可精准过滤电源及信号线路中的电磁干扰、尖峰脉冲，抑制共模与差模干扰，保障接口信号传输的稳定性与完整性，避免干扰导致设备误动作。
高容适配，安全防护：额定电流20A，适配ME-MAX/NEF系列接口及QUINT电源输出端，兼容多种工业接口规格。内置过流保护机制，搭配PCB三防漆工艺，防护性能优异，隔离电压达标，避免接口烧毁或设备损坏。
工业级耐候，稳定可靠：适配-40℃~70℃宽温工作环境，可耐受工业场景振动、温湿度剧烈波动及腐蚀性气体，在极端工况下仍能保持滤波性能稳定，满足长期连续运行需求。
便捷安装，运维高效：采用紧凑结构设计，支持35mm标准DIN卡轨安装，不占用过多控制柜空间。接口防误插设计，接线便捷，可快速与电源、工控设备对接，后期无需频繁维护，降低运维成本。
核心应用领域
广泛应用于工业自动化控制系统、电力测控设备、冶金化工生产线等领域，专为QUINT系列电源配套，适配PLC、传感器、变送器等设备的信号接口与电源接口，有效提升系统抗干扰能力，保障设备在复杂电磁环境下稳定运行。
ME-MAX/NEF/QUINT20A接口过滤器 英文资料：
ME-MAX/NEF/QUINT20A is an industrial grade interface filter designed specifically for QUINT series power supplies and industrial equipment interfaces. Its core functions include electromagnetic interference filtering and signal purification, with high adaptability and reliable protection. It is a key component for ensuring industrial interface stability. Its core features and application areas are as follows:
Core product features
Efficient filtering and signal purification: Integrated with GDT+MOV cooperative surge protection circuit, it can accurately filter electromagnetic interference and peak pulses in power and signal lines, suppress common mode and differential mode interference, ensure the stability and integrity of interface signal transmission, and avoid interference causing equipment misoperation.
High compatibility and safety protection: rated current of 20A, compatible with ME-MAX/NEF series interfaces and QUINT power output terminals, compatible with multiple industrial interface specifications. Built in overcurrent protection mechanism, combined with PCB three proof paint process, excellent protection performance, isolation voltage standard, avoiding interface burnout or equipment damage.
Industrial grade weather resistance, stable and reliable: Suitable for working environments with a wide temperature range of -40 ℃~70 ℃, it can withstand industrial scene vibrations, severe fluctuations in temperature and humidity, and corrosive gases. It can maintain stable filtering performance even under extreme working conditions, meeting long-term continuous operation requirements.
Convenient installation, efficient operation and maintenance: adopting a compact structure design, supporting 35mm standard DIN rail installation, without occupying too much control cabinet space. The interface is designed to prevent accidental insertion, with convenient wiring that can quickly connect with power supplies and industrial control equipment. There is no need for frequent maintenance in the later stage, reducing operation and maintenance costs.
Core application areas
Widely used in industrial automation control systems, power measurement and control equipment, metallurgical and chemical production lines and other fields, it is specially designed to match the QUINT series power supply, adapt to the signal interface and power interface of PLC, sensors, transmitters and other equipment, effectively enhance the system's anti-interference ability, and ensure the stable operation of equipment in complex electromagnetic environments.
