57310001-KD DSBC172总线重复模块产品特点
1. 双网段桥接：支持连接两个Profibus-DP网段，实现不同网段数据双向交互，有效拓展工业总线覆盖范围。
2. 速率灵活适配：允许两个网段采用不同通讯速率，适配多速率混合总线场景，兼容性大幅提升。
3. 电气隔离防护：网段间采用电气隔离设计，杜绝干扰串扰，单个网段故障不影响另一网段正常运行。
4. 大容量数据传输：支持最高244字节输入/输出数据区，满足多设备并发大数据交互需求。
5. 灵活地址配置：支持拨码开关、Step7软件双模式设定站地址，适配现场快速调试与远程组态需求。
6. 全模式诊断功能：支持DPV1全模式诊断，实时监测总线状态与模块运行情况，异常时及时告警提示。
7. 双路冗余供电：配备双路24V DC冗余供电设计，保障模块不间断稳定运行，强化系统可靠性。
8. 便捷组态集成：可无缝对接S7系列PLC，支持多I/O数据交换区自由组态，简化整体系统搭建流程。
9. 工业级环境耐受：适配-20°C至+60°C宽工作温度，IP20防护等级，轻松应对严苛工业现场环境。
10. 信号放大增强：内置信号放大电路，补偿总线传输损耗，延长单网段传输距离，保障远距离信号稳定。
11. 紧凑安装设计：体积小巧适配标准机柜安装，占用空间小，便于高密度总线设备布局。
12. 反向极性保护：具备电源反向极性保护功能，避免接线误操作导致模块损坏，提升安装安全性。
13. 合规品质保障：符合国际工业总线标准，原厂严格品质管控，适配工业自动化长期稳定运行需求。
57310001-KD DSBC172总线重复模块 英文资料：
57310001-KD DSBC172 Bus Repetitive Module Product Features
1. Dual network segment bridging: supports connecting two Profibus DP network segments to achieve bidirectional data exchange between different network segments, effectively expanding the coverage range of industrial buses.
2. Flexible adaptation of speed: allows two network segments to use different communication speeds, adapts to multi speed hybrid bus scenarios, and greatly improves compatibility.
3. Electrical isolation protection: Electrical isolation design is adopted between network segments to eliminate interference and crosstalk, and the failure of a single network segment does not affect the normal operation of another network segment.
4. Large capacity data transmission: Supports up to 244 bytes of input/output data area, meeting the concurrent big data interaction needs of multiple devices.
5. Flexible address configuration: Supports dip switch and Step7 software dual-mode setting of station addresses, adapting to on-site rapid debugging and remote configuration requirements.
6. Full mode diagnostic function: Supports DPV1 full mode diagnosis, real-time monitoring of bus status and module operation, and timely alarm prompts in case of abnormalities.
7. Dual redundant power supply: equipped with dual 24V DC redundant power supply design, ensuring uninterrupted and stable operation of the module, and enhancing system reliability.
8. Convenient configuration integration: It can seamlessly integrate with S7 series PLCs, support free configuration of multiple I/O data exchange areas, and simplify the overall system construction process.
9. Industrial grade environmental tolerance: Suitable for a wide working temperature range of -20 ° C to+60 ° C, with an IP20 protection level, making it easy to cope with harsh industrial site environments.
10. Signal amplification enhancement: Built in signal amplification circuit, compensates for bus transmission loss, extends single segment transmission distance, and ensures stable long-distance signals.
11. Compact installation design: The compact size is suitable for standard cabinet installation, occupying small space and facilitating high-density bus equipment layout.
12. Reverse polarity protection: It has the function of reverse polarity protection for power supply, avoiding module damage caused by wiring errors and improving installation safety.
13. Compliance and Quality Assurance: Compliant with international industrial bus standards, strict quality control by the original factory, and suitable for the long-term stable operation needs of industrial automation.
