1.产 品 资 料 介 绍：
57310001-KH DSBC173总线中继器模块产品特点
1. 总线信号中继：专为Profibus-DP总线设计，可有效放大总线信号，补偿传输损耗，显著延长总线整体覆盖距离。
2. 双网段隔离衔接：支持两个Profibus-DP网段的隔离连接，阻断网段间干扰串扰，提升总线系统稳定性。
3. 内置编程功能：具备结构化编程能力，可适配工业控制场景的个性化逻辑需求，灵活拓展应用场景。
4. 速率自适应匹配：可自动适配不同网段通讯速率，无需手动调试，兼容多速率混合总线系统，通用性强。
5. 电气隔离防护：网段间采用高耐压电气隔离设计，单个网段故障不影响另一网段运行，保障系统容错性。
6. 全功能状态诊断：支持DPV1标准全模式诊断，实时监测总线信号、模块运行状态，异常时快速告警提示。
7. 双路冗余供电：配备24V DC双路冗余供电接口，避免单点供电故障，确保模块不间断稳定运行。
8. 便捷组态集成：无缝对接S7系列PLC及主流工业控制系统，支持快速组态调试，简化系统搭建流程。
9. 宽温环境适配：工作温度覆盖-20°C至+60°C，IP20防护等级，可在高低温、多粉尘工业场景稳定运行。
10. 反向极性保护：具备电源反向极性防护功能，有效避免接线误操作导致模块损坏，提升安装安全性。
11. 紧凑机柜安装：体积小巧贴合标准机柜布局，占用空间小，适配高密度总线设备集中安装需求。
12. 高兼容性设计：作为成熟总线中继方案，可兼容前代同类模块，适配存量系统升级改造场景。
11. 紧凑安装设计：体积小巧适配标准机柜安装，占用空间小，便于高密度总线设备布局。
12. 反向极性保护：具备电源反向极性保护功能，避免接线误操作导致模块损坏，提升安装安全性。
13. 原厂品质保障：符合国际工业总线标准，原厂严格品控，适配工业自动化长期稳定运行及维保需求。
57310001-KH DSBC173总线中继器模块 英文资料：
57310001-KH DSBC173 bus repeater module product features
1. Bus signal relay: specially designed for Profibus DP bus, it can effectively amplify bus signals, compensate for transmission losses, and significantly extend the overall coverage distance of the bus.
2. Dual network segment isolation connection: supports isolated connection between two Profibus DP network segments, blocks interference and crosstalk between network segments, and improves the stability of the bus system.
3. Built in programming function: With structured programming capability, it can adapt to personalized logic requirements of industrial control scenarios and flexibly expand application scenarios.
4. Rate adaptive matching: It can automatically adapt to different network segment communication rates without manual debugging, compatible with multi rate hybrid bus systems, and has strong universality.
5. Electrical isolation protection: High voltage electrical isolation design is adopted between network segments, and the failure of a single network segment does not affect the operation of another network segment, ensuring system fault tolerance.
6. Full function status diagnosis: Supports DPV1 standard full mode diagnosis, real-time monitoring of bus signals and module operation status, and quick alarm prompts in case of abnormalities.
7. Dual redundant power supply: equipped with 24V DC dual redundant power supply interface to avoid single point power supply failure and ensure uninterrupted and stable operation of the module.
8. Convenient configuration integration: Seamless integration with S7 series PLC and mainstream industrial control systems, supporting fast configuration and debugging, simplifying the system construction process.
9. Wide temperature environment adaptation: The working temperature covers -20 ° C to+60 ° C, with an IP20 protection level, and can operate stably in high and low temperature, multi dust industrial scenarios.
10. Reverse polarity protection: It has the function of reverse polarity protection for power supply, effectively avoiding module damage caused by wiring errors and improving installation safety.
11. Compact cabinet installation: With a compact size that fits the standard cabinet layout, it occupies less space and is suitable for centralized installation of high-density bus equipment.
12. High compatibility design: As a mature bus relay solution, it is compatible with previous generations of similar modules and suitable for upgrading and transforming existing systems.
11. Compact installation design: The compact size is suitable for standard cabinet installation, occupying small space and facilitating high-density bus equipment layout.
12. Reverse polarity protection: It has the function of reverse polarity protection for power supply, avoiding module damage caused by wiring errors and improving installation safety.
13. Original factory quality assurance: Compliant with international industrial bus standards, strictly controlled by the original factory, suitable for long-term stable operation and maintenance needs of industrial automation.
