SEW MDV60A0015-5A3-4-00伺服驱动器

SEW MDV60A0015-5A3-4-00伺服驱动器

1.产 品 资 料 介 绍：

15 条核心特点

1. 额定功率：1.5kW，三相 380–500V 输入，50/60Hz 通用。
2. 额定电流：输入 3.6A（400V），输出 4.0A（400V），适配小功率伺服电机。
3. 控制模式：支持 VFC（电压磁通控制）、CFC（电流磁通控制）、SERVO 伺服模式，带 / 不带编码器均可。
4. 闭环精度：支持增量式编码器、旋转变压器反馈，实现位置 / 速度 / 转矩三闭环控制。
5. 过载能力：150% 额定电流可持续 60 秒，200% 短时过载，适应冲击负载。
6. 输出频率：0.1–400Hz 可调，满足高速精准定位需求。
7. 内置 IPOSplus：集成定位与顺序控制功能，支持多段速、点对点定位，无需额外 PLC。
8. 安全功能：内置 STO（安全转矩关断），符合 SIL2 安全等级，支持安全停机。
9. 通信接口：标配 RS-485，支持 PROFIBUS、PROFINET、DeviceNet、Modbus 等总线（需扩展卡）。
10. I/O 配置：6 路隔离数字输入、3 路数字输出（含可编程继电器），2 路模拟量输入 / 输出。
11. 保护功能：过压、欠压、过流、过热、电机堵转、接地故障、编码器异常全保护。
12. 散热设计：强制风冷，紧凑结构，适应连续满负荷运行。
13. EMC 性能：内置 C3 级 EMC 滤波器，符合 EN 61800-3 标准，抗干扰强。
14. 参数存储：128kB FRAM，掉电保持参数，无需电池备份。
15. 应用场景：包装机械、印刷设备、机器人、输送线、精密定位平台等高精度传动场景。

结尾

SEW MDV60A0015-5A3-4-00伺服驱动器  英文资料：

SEW MDV60A0015-5A3-4-00 is a 1.5kW high-performance servo drive from MOVIDRIVE MD-60A series, featuring vector closed-loop control, high dynamic response, and industrial bus compatibility, suitable for asynchronous/synchronous servo motors.

15 core characteristics

Rated power: 1.5kW, three-phase 380-500V input, 50/60Hz universal.

Rated current: Input 3.6A (400V), output 4.0A (400V), suitable for low-power servo motors.

Control mode: Supports VFC (Voltage Flux Control), CFC (Current Flux Control), SERVO servo mode, with or without encoder.

Closed loop accuracy: Supports incremental encoders and feedback from rotary transformers to achieve position/velocity/torque triple loop control.

Overload capacity: 150% rated current can last for 60 seconds, 200% short-term overload, suitable for impact loads.

Output frequency: adjustable from 0.1-400Hz, meeting the requirements of high-speed and precise positioning.

Built in IPOSplus: integrates positioning and sequential control functions, supports multi-stage speed, point-to-point positioning, and does not require an additional PLC.

Safety function: Built in STO (Safe Torque Off), meets SIL2 safety level, supports safe shutdown.

Communication interface: Standard RS-485, supports PROFIBUS, PROFINET, DeviceNet, Modbus and other buses (requires expansion card).

I/O configuration: 6 isolated digital inputs, 3 digital outputs (including programmable relays), 2 analog inputs/outputs.

Protection function: Full protection against overvoltage, undervoltage, overcurrent, overheating, motor stalling, ground fault, and encoder abnormality.

Heat dissipation design: forced air cooling, compact structure, suitable for continuous full load operation.

EMC performance: Built in C3 level EMC filter, compliant with EN 61800-3 standard, strong anti-interference.

Parameter storage: 128kB FRAM, keep parameters in case of power failure, no need for battery backup.

Application scenarios: high-precision transmission scenarios such as packaging machinery, printing equipment, robots, conveyor lines, precision positioning platforms, etc.

ending

MDV60A0015-5A3-4-00 has become the mainstream choice for low-power high-precision servo drives due to its high dynamic performance, high reliability, and strong compatibility.
