1.产 品 资 料 介 绍：
NACHI BUY222 伺服放大器单元
一、核心定位与功能
- 电液伺服驱动：接收 ±10V 指令信号，与反馈信号比较、放大后输出控制电流，驱动伺服阀力矩电机，精准控制阀芯开度。
- 闭环控制核心：内置信号调理、PID 运算与限幅保护，构成完整闭环，保证液压执行机构的位置 / 速度 / 压力精度。
- 宽压供电：支持 AC 200–220V 输入，适配工业现场电网。
- 电流输出可调：输出电流范围 ±10–±100mA，兼容多数 NACHI 及 MOOG 系列伺服阀。
- 多重保护：内置过流、短路、过热、最大电流限幅，防止伺服阀与放大器损坏。
- 高响应带宽：典型带宽 1200Hz，满足高速动态控制需求。
- 反馈接口：支持位移 / 压力传感器反馈输入，实现全闭环控制。
- 状态指示：板载 LED 显示电源、运行、报警状态，便于现场诊断。
- 工业级可靠：宽温、抗振、EMC 防护，适配车间恶劣环境。
- 模块化结构：独立单元设计，便于安装、调试与更换，降低维护难度。
- 适配机型：多用于 NACHI SA160 等系列机器人及重型液压设备。
- 重量：约 11.79kg（26lbs），结构坚固。
- 应用场景：机器人关节控制、机床液压轴、注塑机锁模 / 射胶、压力机精密压装等。
NACHI BUY222伺服放大器单元 英文资料：
NACHI BUY222 servo amplifier unit
NACHI BUY222 is a specialized servo amplifier unit designed by NACHI-FUJIKOSHI for electro-hydraulic servo systems. It is mainly used to drive servo valves and achieve high-precision closed-loop control of hydraulic systems. It is commonly used in heavy industrial equipment such as robots, machine tools, injection molding machines, and presses. This model has been discontinued, but it is still widely used in existing equipment.
1、 Core positioning and functions
Electro hydraulic servo drive: receives ± 10V command signal, compares and amplifies it with feedback signal, outputs control current, drives servo valve torque motor, and accurately controls valve core opening.
Closed loop control core: Built in signal conditioning, PID operation, and limiting protection, forming a complete closed loop to ensure the position/speed/pressure accuracy of the hydraulic actuator.
Wide voltage power supply: supports AC 200-220V input and is compatible with industrial site power grids.
Adjustable current output: The output current range is ± 10- ± 100mA, compatible with most NACHI and MOOG series servo valves.
Multiple protections: Built in overcurrent, short circuit, overheating, and maximum current limiting to prevent damage to servo valves and amplifiers.
High response bandwidth: Typical bandwidth of 1200Hz, meeting the requirements of high-speed dynamic control.
Feedback interface: Supports feedback input from displacement/pressure sensors to achieve full closed-loop control.
Status indication: Onboard LED displays power, operation, and alarm status for easy on-site diagnosis.
Industrial grade reliability: wide temperature range, anti vibration, EMC protection, suitable for harsh environments in workshops.
Modular structure: Independent unit design, easy to install, debug, and ｒｅｐｌａｃｅ, reducing maintenance difficulty.
Compatible models: mostly used for NACHI SA160 series robots and heavy-duty hydraulic equipment.
Weight: Approximately 11.79kg (26lbs), sturdy structure.
Application scenarios: robot joint control, machine tool hydraulic axis, injection molding machine locking/injection molding, precision press fitting of press machines, etc.
NACHI BUY222伺服放大器单元 产品展示
产品视频
