PHILIPS PR1613称重机显示屏

1.产 品 资 料 介 绍：

PHILIPS PR1613 称重机显示仪表

1. 显示配置：主显示为7 段真空荧光绿屏，字符高度 12.5mm，附称重 / 状态符号；/03/04 不锈钢外壳版本额外带 2 行 20 字符的 5×7 点阵中文 / 多语言信息屏
2. 处理器与控制：内置可编程 PLC，支持称重流程定制，自动零点跟踪，多量程切换（3 量程）
3. 传感器接口：支持 4 线 / 6 线称重传感器，可选 12V/20V 传感器供电，可接多组传感器
4. 通信扩展：最多 4 路串口（TTY/RS232/RS422/485），可选 PROFIBUS-DP、模拟量 I/O、BCD 输出、打印机接口
5. 输入输出：6 路光隔输入，12 路光隔输出，可自定义称重逻辑联动
6. 供电版本：/00/03 为 110/220V AC；/01/04 为 24V AC/DC 工业电源
7. 防护等级：/00/01 铝壳 IP30 机身、面板 IP65；/03/04 全不锈钢 IP65 整机
8. 精度指标：符合 EN45501（OIML R76），5000e III 级，内部分辨率最高 180000 计数
9. 环境耐受：宽温工作（工业 - 10℃至 + 55℃），抗振动、抗电磁干扰，符合工业 EMC 标准
10. 校准方式：支持免砝码校准（输入传感器参数），多语言操作界面
11. 典型应用：汽车衡、平台秤、配料系统、起重机称重、车载称重
12. 功耗参数：AC 版本约 19–22.5W，DC 版本约 18–23W，功耗低适合长时间运行
13. 存储与时钟：可选内存扩展、法定称重数据备份（Alibi memory），/03 标配独立 RTC
14. 安装形式：面板嵌入式安装，适配标准控制柜开孔
15. 存量状态：经典工业备件，适用于老旧称重系统维护升级，部分地区有专业维修与配件供应
16. 显示优势：荧光屏亮度高，工业环境下远距离清晰可读，点阵屏版本支持详细操作提示与报错
17. 安全合规：具备称重法规认证，支持数据防篡改，满足贸易结算场景要求

PHILIPS PR1613称重机显示屏 英文资料：

PHILIPS PR1613 Weighing Machine Display Instrument

PR1613 is an industrial grade high-precision weighing display controller from Philips (Sartorius OEM/cooperation), divided into multiple sub models (/00/01/03/04), not just a display screen but an integrated instrument with complete weighing control.

Display configuration: The main display is a 7-segment vacuum fluorescent green screen, with a character height of 12.5mm and attached weighing/status symbols; /03/04 Stainless steel shell version with additional 2 lines of 20 characters 5 × 7 dot matrix Chinese/multilingual information screen

Processor and Control: Built in programmable PLC, supports customized weighing process, automatic zero point tracking, multi range switching (3 ranges)

Sensor interface: Supports 4-wire/6-wire weighing sensors, optional 12V/20V sensor power supply, can connect multiple sets of sensors

Communication Expansion: Up to 4 serial ports (TTY/RS232/RS422/485), optional PROFIBUS-DP, analog I/O, BCD output, printer interface

Input/output: 6 optical isolated inputs, 12 optical isolated outputs, customizable weighing logic linkage

Power supply version:/00/03 is 110/220V AC; /01/04 is a 24V AC/DC industrial power supply

Protection level:/00/01 aluminum shell IP30 body, panel IP65; /03/04 Full stainless steel IP65 complete machine

Accuracy index: Complies with EN45501 (OIML R76), 5000e Level III, internal resolution up to 180000 counts

Environmental tolerance: Wide temperature operation (industrial -10 ℃ to+55 ℃), anti vibration, anti electromagnetic interference, in compliance with industrial EMC standards

Calibration method: Supports weight free calibration (input sensor parameters), multilingual operation interface

Typical applications: truck scale, platform scale, batching system, crane weighing, vehicle mounted weighing

Power consumption parameters: AC version about 19-22.5W, DC version about 18-23W, low power consumption suitable for long-term operation

Storage and clock: optional memory expansion, Alibi memory backup for legal weighing data, and/03 standard independent RTC

Installation form: panel embedded installation, compatible with standard control cabinet openings

Stock status: Classic industrial spare parts, suitable for maintenance and upgrading of old weighing systems, with professional maintenance and parts supply in some areas

Display advantages: high brightness of fluorescent screen, clear and readable from a distance in industrial environment, dot matrix screen version supports detailed operation prompts and error messages

Security compliance: Equipped with weighing regulation certification, supporting data tampering prevention, and meeting the requirements of trade settlement scenarios

PHILIPS PR1613称重机显示屏 产品展示
