ALCATEL LUCENT 3BA53065NA印刷电路板

ALCATEL LUCENT  3BA53065NA印刷电路板

1.产 品 资 料 介 绍：

中文资料：

ALCATEL LUCENT 3BA53065NA 印刷电路板（又称 Z24-2 模拟扩展板）

产品简介：
这是一款用于 Alcatel-Lucent OmniPCX Enterprise 电话系统的扩展模块，主要负责提供24个模拟用户接口，适用于连接传统模拟电话设备，如传真机、电话机或门禁对讲设备。它属于该通信平台的可插拔模块之一，具备高可靠性和系统兼容性。

核心功能：

• 支持24个模拟终端接口，适配常规POTS设备

• 通过系统总线与主控板连接，实现统一管理

• 支持模拟呼叫、传真、语音邮件等基础功能

• 可进行远程配置与故障诊断

• 热插拔设计，维护与更换便捷

应用领域：

1. 企业通信系统：用于扩展办公楼中模拟电话的部署数量。

2. 酒店通信网络：满足酒店房间内模拟电话连接需求。

3. 医疗行业：连接护士站、病房等位置的模拟终端设备。

4. 呼叫中心：支持大量座席使用模拟电话进行客户沟通。

5. 教育系统：部署于学校、实验室或办公区域的电话通信。

英文资料：

ALCATEL LUCENT 3BA53065NA Printed Circuit Board (also known as Z24-2 Analog Expansion Board)

Product Introduction:

This is an expansion module for Alcatel Lucent OmniPCX Enterprise telephone systems, mainly responsible for providing 24 analog user interfaces, suitable for connecting traditional analog telephone devices such as fax machines, telephones, or access control intercom devices. It is one of the pluggable modules of the communication platform, with high reliability and system compatibility.

Core functions:

Supports 24 simulated terminal interfaces, compatible with conventional POS devices

Connect to the main control board through the system bus to achieve unified management

Support basic functions such as simulated calling, fax, voice mail, etc

Can perform remote configuration and fault diagnosis

Hot swappable design, easy maintenance and replacement

Application areas:

Enterprise communication system: used to expand the deployment of analog telephones in office buildings.

Hotel communication network: meets the analog telephone connection requirements in hotel rooms.

Medical industry: analog terminal devices that connect nurse stations, wards, and other locations.

Call Center: Supports a large number of agents to use analog phones for customer communication.

Education system: Telephone communication deployed in schools, laboratories, or office areas.

2.产      品      展      示
