Hirschmann MM3-2FXM2 2TX1媒体模块
1.产 品 资 料 介 绍：
中文资料：
Hirschmann MM3-2FXM2 2TX1 是 Hirschmann 提供的一款高性能工业媒体模块，专为网络中设备之间的数据传输提供扩展支持。该模块设计用于提供两路光纤接口（2FX）与一路以太网接口（2TX1），实现光纤到以太网的信号转换，广泛应用于工业自动化和通信网络中，特别是在需要长距离传输和网络冗余的环境中。
主要技术参数
| 项目 | 参数说明 |
|---|---|
| 模块类型 | 光纤/以太网媒体转换模块 |
| 光纤接口类型 | 2 路 SC/LC 光纤接口（单模或多模） |
| 以太网接口类型 | 1 路 10/100/1000 Mbps 以太网端口 |
| 光纤接口标准 | 支持 IEEE 802.3 10BASE-FL、100BASE-FX、1000BASE-SX |
| 网络冗余支持 | 支持网络冗余（如 RSTP、PRP、Hirschmann 提供的工业协议） |
| 电源供应 | 24V DC（典型） |
| 工作温度范围 | -40°C 至 +75°C |
| 环境适应性 | 防尘、防水，符合 IP30 或更高等级 |
| 安装方式 | DIN 导轨安装（标准安装方式） |
| 使用标准 | IEC 61850-3、IEEE 802.3、UL/CE 认证 |
| LED 状态指示 | 提供操作和故障指示灯 |
光纤与以太网信号转换：支持从光纤到以太网的数据流转换，适用于工业网络的长距离传输需求
冗余与可靠性：支持高可用性和冗余网络配置，减少系统故障时间，确保网络的高稳定性
高温工作环境：适用于严苛的工业环境，支持极端温度下稳定工作
紧凑设计：小巧的模块设计，适用于空间有限的控制柜或设备中
扩展性：可与 Hirschmann 其他工业网络设备无缝集成，满足多种网络拓扑需求
易于安装与维护：简单的 DIN 导轨安装，提供便捷的系统监控和管理功能
强大的协议支持：兼容多种工业协议和网络标准，支持多种网络架构
英文资料：
Hirschmann MM3-2FXM2 2TX1 is a high-performance industrial media module provided by Hirschmann, designed to provide extended support for data transmission between devices in networks. This module is designed to provide two fiber optic interfaces (2FX) and one Ethernet interface (2TX1) to achieve signal conversion from fiber optic to Ethernet. It is widely used in industrial automation and communication networks, especially in environments that require long-distance transmission and network redundancy.
Main technical parameters
Project parameter description
Module type: Fiber optic/Ethernet media conversion module
Fiber interface type: 2-channel SC/LC fiber interface (single-mode or multi-mode)
Ethernet interface type: 1-channel 10/100/1000 Mbps Ethernet port
The fiber optic interface standard supports IEEE 802.3 10BASE-FL, 100BASE-FX, and 1000BASE-SX
Network redundancy support supports network redundancy (such as RSTP, PRP, industrial protocols provided by Hirschmann)
Power supply 24V DC (typical)
Working temperature range -40 ° C to+75 ° C
Environmental adaptability: dustproof and waterproof, compliant with IP30 or higher levels
Installation method: DIN rail installation (standard installation method)
Use standard IEC 61850-3, IEEE 802.3, UL/CE certification
LED status indicator provides operation and fault indicator lights
Product Features
Fiber optic and Ethernet signal conversion: supports data stream conversion from fiber optic to Ethernet, suitable for long-distance transmission needs in industrial networks
Redundancy and Reliability: Supports high availability and redundant network configurations, reduces system failure time, and ensures high network stability
High temperature working environment: suitable for harsh industrial environments, supporting stable operation under extreme temperatures
Compact design: A compact module design suitable for control cabinets or devices with limited space
Scalability: Seamless integration with other Hirschmann industrial network devices to meet various network topology requirements
Easy to install and maintain: Simple DIN rail installation, providing convenient system monitoring and management functions
Powerful protocol support: compatible with multiple industrial protocols and network standards, supporting multiple network architectures
2.产 品 展 示
