AEG PC-E984-685R 可编程控制器模块

AEG PC-E984-685R 可编程控制器模块

1.产 品 资 料 介 绍：

中文资料：

AEG PC-E984-685R 可编程控制器模块 是施耐德电气（Schneider Electric）旗下 AEG 品牌早期推出的一款工业级 PLC 控制模块，主要用于工业自动化控制系统中的逻辑处理、设备控制与通信集成。它属于 Modicon 984 系列，这一系列曾广泛应用于过程控制、工厂自动化、电力系统和重型机械控制中。

一、产品基本信息

• 型号：PC-E984-685R

• 制造商：AEG / Modicon（现为施耐德电气旗下品牌）

• 产品类别：可编程逻辑控制器（PLC）主模块

• 系列归属：Modicon 984 系列（高端模块）

二、功能特性

1. 高性能 CPU 处理能力

   • 搭载高速工业处理器，适合多任务逻辑处理，支持复杂控制逻辑和数据运算。

   • 适用于中到大型自动化控制项目。

2. 模块化架构

   • 支持 I/O 模块热插拔（视配置而定），具备良好的可扩展性与兼容性。

   • 可连接多种 984 系列 I/O 扩展模块。

3. 支持多种通信协议

   • 可通过附加通信模块接入 Modbus、Modbus Plus、TCP/IP、SY/MAX 等工业通信网络。

   • 适合与上位机、SCADA、人机界面（HMI）等系统进行实时数据交互。

4. 强大的编程支持

   • 使用 Modsoft、Concept、ProWORX 等编程软件进行逻辑开发。

   • 支持多种编程语言，包括梯形图（Ladder）、功能块图（FBD）等。

5. 工业级耐用性设计

   • 工作温度范围广，抗电磁干扰能力强，适应各种工业现场环境。

   • 采用冗余电源设计，可支持热备份配置（取决于系统整体架构）。

三、技术参数概览（典型配置）

英文资料：

The AEG PC-E984-685R programmable controller module is an industrial grade PLC control module launched early by the AEG brand under Schneider Electric. It is mainly used for logic processing, equipment control, and communication integration in industrial automation control systems. It belongs to the Modicon 984 series, which has been widely used in process control, factory automation, power systems, and heavy machinery control.

1、 Basic Product Information

Model: PC-E984-685R

Manufacturer: AEG/Modicon (now a brand under Schneider Electric)

Product Category: Programmable Logic Controller (PLC) Main Module

Series affiliation: Modicon 984 series (high-end module)

2、 Functional characteristics

High performance CPU processing capability

Equipped with high-speed industrial processors, suitable for multitasking logic processing, supporting complex control logic and data operations.

Suitable for medium to large-scale automation control projects.

Modular architecture

Supports hot plugging of I/O modules (depending on configuration), with good scalability and compatibility.

Can connect multiple 984 series I/O expansion modules.

Support multiple communication protocols

It can be connected to industrial communication networks such as Modbus, Modbus Plus, TCP/IP, SY/MAX through additional communication modules.

Suitable for use with upper computers SCADA、 Real time data exchange is carried out through human-machine interface (HMI) and other systems.

Powerful programming support

Use programming software such as Modsoft, Concept, ProWORX for logic development.

Supports multiple programming languages, including ladder diagram (Ladder), functional block diagram (FBD), etc.

Industrial grade durability design

Wide working temperature range, strong electromagnetic interference resistance, and adaptability to various industrial site environments.

Adopting redundant power supply design, it can support hot backup configuration (depending on the overall system architecture).

3、 Overview of Technical Parameters (Typical Configuration)

Project parameter description

CPU industrial grade high-performance processor (model by version)

Storage capacity: RAM and non-volatile memory (optional configuration)

Communication port serial port RS-232/485, Modbus Plus, etc

Programming interface: Universal serial port or Modbus communication

Power input 5V/24V DC (requires external power module)

Installation method: Modular rail or backplate installation

The operating environment temperature ranges from 0 to 60 ° C (depending on the specific installation situation)

Industrial level electromagnetic compatibility standard for anti-interference capability

Modular structure for size/weight, standardized installation dimensions

2.产      品      展      示
