Siemens 6ES7317-2FK14-0AB0 中央处理单元
1.产 品 资 料 介 绍：
中文资料：
Siemens 6ES7317-2FK14-0AB0 是西门子 S7-300 系列中的一款强性能中央处理单元（CPU），型号为 CPU 317-2 PN/DP，具有良好的处理能力、集成以太网（PROFINET）与 PROFIBUS 接口，适用于中大型自动化控制系统。
一、产品概述
| 项目 | 说明 |
|---|---|
| 产品型号 | 6ES7317-2FK14-0AB0 |
| 产品名称 | SIMATIC S7-300 CPU 317-2 PN/DP 中央处理单元 |
| 系列 | SIMATIC S7-300 |
| 制造商 | Siemens（西门子） |
| CPU 类型 | CPU 317-2 PN/DP |
| 应用领域 | 中大型 PLC 控制系统，工厂自动化、过程控制、电力、交通等 |
| 参数 | 数据说明 |
|---|---|
| 处理器性能 | 中等偏上，适用于复杂控制任务 |
| 工作存储器 | 1 MB（负载存储器）/ 256 KB（工作存储器） |
| 指令执行时间 | 位操作约 0.06 μs，字操作约 0.1 μs |
| 数字 I/O 点数支持 | 可通过模块扩展，支持大量数字量输入/输出 |
| 模拟 I/O | 通过扩展模块支持 |
| 通信端口 | - 1 × PROFINET（带 RJ45 接口） - 1 × PROFIBUS DP 主站/从站 |
| 通讯协议 | MPI, PROFIBUS DP, PROFINET IO |
| 时钟 | 内置实时时钟 |
| 编程语言 | LAD, FBD, STL, SCL, Graph |
| 最大模块数 | 可扩展至 32 个模块（需搭配合适电源/扩展机架） |
| 电源电压 | 24 V DC |
| 尺寸 (宽×高×深) | 80 × 125 × 130 mm |
| 安装方式 | DIN 导轨安装 |
| 工作温度 | 0～60°C |
英文资料：
Siemens 6ES7317-2FK14-0AB0 is a high-performance central processing unit (CPU) in the Siemens S7-300 series, with the model number CPU 317-2 PN/DP. It has good processing capabilities, integrated Ethernet (PROFINET) and PROFIBUS interfaces, and is suitable for medium to large automation control systems.
1、 Product Overview
Project Description
Product model 6ES7317-2FK14-0AB0
Product Name SIMATIC S7-300 CPU 317-2 PN/DP Central Processing Unit
Series SIMATIC S7-300
Manufacturer Siemens
CPU type: CPU 317-2 PN/DP
Large scale PLC control systems in application fields such as factory automation, process control, power, transportation, etc
2、 Main technical parameters
Parameter Data Description
The processor performance is above average and suitable for complex control tasks
Work memory 1 MB (load memory)/256 KB (work memory)
Instruction execution time bit operation is about 0.06 μ s, word operation is about 0.1 μ s
Digital I/O point support can be expanded through modules, supporting a large number of digital inputs/outputs
Simulated I/O supported through expansion modules
Communication port -1 x PROFINET (with RJ45 interface)
-1 x PROFIBUS DP master/slave
Communication protocols MPI, PROFIBUS DP, PROFINET IO
Built in real-time clock
Programming languages LAD, FBD, STL, SCL, Graph
The maximum number of modules can be expanded to 32 (with appropriate power supply/expansion rack)
Power supply voltage 24 V DC
Dimensions (width x height x depth) 80 x 125 x 130 mm
Installation method: DIN rail installation
Working temperature 0-60 ° C
2.产 品 展 示
