EATON PL9-C2-2 微型断路器

 EATON PL9-C2-2 微型断路器

1.产 品 资 料 介 绍：

中文资料：

EATON PL9-C2-2 微型断路器 是一款由伊顿（Eaton）公司生产的用于低压配电系统中的模块化断路器，具有高可靠性和良好的过载及短路保护性能。以下是其产品概述与应用领域介绍：

一、产品基本信息

• 型号：PL9-C2-2

• 类型：微型断路器（Miniature Circuit Breaker，MCB）

• 极数：2极（双极）

• 额定电流：2 A

• 脱扣曲线：C型（C Curve，适用于常规电阻性和轻度感性负载）

• 额定电压：一般为230/400V AC（取决于地区标准）

• 分断能力：通常为6kA（需结合具体系列确认）

• 安装方式：DIN导轨安装

• 符合标准：IEC/EN 60898-1

二、产品特点

• 提供双极隔离保护，可用于双线系统的同时断开

• 快速断开机制，可在过流或短路发生时迅速切断电源

• 体积小巧，适用于标准电气配电箱

• C型脱扣特性，适合电动机、小型变压器和照明负载

• 高机械与电气寿命，适合频繁操作

三、应用领域

1. 住宅与商业建筑

   • 用于家庭电路分支保护，例如照明、插座线路

   • 保护建筑中普通电气设备免受过载和短路损害

2. 工业控制系统

   • 小型工业设备、控制柜、分布式系统中的电路保护

   • 可用于PLC输入输出模块、电磁阀控制线路的短路保护

3. 配电板与电气控制柜

   • 作为控制柜中的分支电路保护元件

   • 确保下游模块设备在电气故障发生时得到安全隔离

4. 电信与IT机房

   • 为电源系统分支线路提供隔离与保护，防止设备损坏

   • 应用于UPS输出分路、电源配电单元中的子保护电路

5. 交通与轨道设备

   • 轨道交通信号箱、电气设备配电箱中使用

   • 提供精确的过流保护，保证系统稳定运行

英文资料：

EATON PL9-C2-2 miniature circuit breaker is a modular circuit breaker produced by Eaton Corporation for use in low-voltage distribution systems, with high reliability and good overload and short-circuit protection performance. The following is an overview of its products and an introduction to its application areas:

1、 Basic Product Information

Model: PL9-C2-2

Type: Miniature Circuit Breaker (MCB)

Number of poles: 2 poles (bipolar)

Rated current: 2 A

Release curve: C-type (C Curve, suitable for conventional resistive and mild inductive loads)

Rated voltage: generally 230/400V AC (depending on regional standards)

Breaking capacity: usually 6kA (to be confirmed with specific series)

Installation method: DIN rail installation

Compliant with standard: IEC/EN 60898-1

2、 Product Features

Provide bipolar isolation protection, which can be used for simultaneous disconnection of dual line systems

Quick disconnect mechanism, which can quickly cut off the power supply in case of overcurrent or short circuit

Compact size, suitable for standard electrical distribution boxes

C-type trip characteristic, suitable for electric motors, small transformers, and lighting loads

High mechanical and electrical lifespan, suitable for frequent operation

3、 Application Fields

Residential and commercial buildings

Used for branch protection of household circuits, such as lighting and socket circuits

Protect ordinary electrical equipment in buildings from overload and short circuit damage

Industrial control system

Circuit protection in small industrial equipment, control cabinets, and distributed systems

Can be used for short-circuit protection of PLC input/output modules and solenoid valve control circuits

Distribution board and electrical control cabinet

As a branch circuit protection component in the control cabinet

Ensure safe isolation of downstream module equipment in the event of electrical failure

Telecommunications and IT room

Provide isolation and protection for power system branch lines to prevent equipment damage

Applied to sub protection circuits in UPS output branches and power distribution units

Transportation and Rail Equipment

Used in rail transit signal boxes and electrical equipment distribution boxes

Provide precise overcurrent protection to ensure stable system operation
