KLA Tencor 820-21036-001组合接口板
1.产 品 资 料 介 绍：
中文资料：
KLA Tencor 820-21036-001 组合接口板（Combined Interface Board） 是KLA Tencor系统中用于集成多种信号输入输出接口的关键电子模块，主要作用是实现多个子系统之间的信号转换、汇聚和分配。该板卡广泛应用于高端半导体检测设备的控制系统中，是实现设备模块化和信号标准化的重要部件。
一、产品基本信息
型号：820-21036-001
类型：组合接口板（Combined Interface Board）
所属平台：KLA Tencor 820系列
功能定位：多通道信号接口整合，实现系统内部模块间高效通信
二、主要功能
多种信号接口集成
支持数字输入/输出、模拟输入/输出、多路传感器信号等多种信号类型的转换与处理。
提供统一接口标准，简化系统内部连接。
信号汇聚与分配
将多个信号源汇总，集中传递至主控模块或下一级控制单元。
反向分配控制信号，支持多模块同步操作。
兼容性强
兼容KLA Tencor多种控制器、驱动器及传感器。
适配不同通信协议和电气标准，方便系统升级和扩展。
信号隔离与保护
具备抗电磁干扰能力，保障信号传输质量。
内置过流、过压保护机制，提高设备安全性。
英文资料：
The KLA Tencor 820-21036-001 Combined Interface Board is a key electronic module used in the KLA Tencor system to integrate multiple signal input and output interfaces. Its main function is to achieve signal conversion, aggregation, and distribution between multiple subsystems. This board is widely used in the control system of high-end semiconductor testing equipment and is an important component for achieving equipment modularization and signal standardization.
1、 Basic Product Information
Model: 820-21036-001
Type: Combined Interface Board
Platform: KLA Tencor 820 Series
Functional positioning: Integration of multi-channel signal interfaces to achieve efficient communication between internal modules of the system
2、 Main functions
Integration of multiple signal interfaces
Support the conversion and processing of various signal types such as digital input/output, analog input/output, and multi-channel sensor signals.
Provide a unified interface standard to simplify internal system connections.
Signal aggregation and distribution
Summarize multiple signal sources and transmit them centrally to the main control module or the next level control unit.
Reverse allocation of control signals, supporting synchronous operation of multiple modules.
Strong compatibility
Compatible with multiple KLA Tencor controllers, drivers, and sensors.
Adapt to different communication protocols and electrical standards to facilitate system upgrades and expansions.
Signal isolation and protection
Capable of resisting electromagnetic interference to ensure the quality of signal transmission.
Built in overcurrent and overvoltage protection mechanisms enhance device safety.
2.产 品 展 示
