KLA Tencor 712-404561-00处理器模块
1.产 品 资 料 介 绍：
中文资料：
KLA Tencor 712-404561-00 处理器模块（Processor Module） 是KLA Tencor高端半导体检测和计量设备中的核心计算与控制单元，主要负责采集数据的高速处理、控制指令的执行和系统功能的整体协调。它是实现设备智能化、自动化运行的重要基础组件。
一、产品概况
产品型号：712-404561-00
类型：处理器模块（Processor Module）
品牌：KLA Tencor
所属系统：KLA Tencor 712系列检测/量测平台
功能定位：设备核心控制与数据处理平台
二、核心功能
| 功能项 | 描述 |
|---|---|
| 中央处理单元 | 搭载高性能嵌入式CPU或工业级处理器，执行复杂的控制算法与任务调度。 |
| 实时数据处理 | 对来自图像板、传感器模块、扫描系统等单元采集的数据进行高速分析与处理。 |
| 系统协调与控制 | 控制并管理整机各子模块的运行状态，实现运动控制、光学控制、数据采集同步等。 |
| 通信接口支持 | 提供多种工业级通信接口（如Ethernet、RS-232/422/485、CAN、USB、PXI等）与其他模块或上位系统交互。 |
| 软件环境支持 | 支持KLA专用操作系统或定制固件，可升级、可远程管理。 |
三、应用领域
晶圆缺陷检测系统
执行缺陷识别、图像处理算法和平台控制策略，实现高速、高精度晶圆表面扫描与分析。自动光学计量系统
控制激光测量、形貌测量、边缘识别等任务，并与图像系统实时联动。平台与扫描系统协调
作为主控单元，与伺服驱动、编码器、图像系统等协同控制，实现稳定、精准的测量动作。数据采集与传输中心
承担大量图像数据、控制数据、传感信号的实时管理与上传。
英文资料：
The KLA Tencor 712-404561-00 processor module is the core computing and control unit in KLA Tencor's high-end semiconductor detection and measurement equipment. It is mainly responsible for high-speed processing of collected data, execution of control instructions, and overall coordination of system functions. It is an important foundational component for achieving intelligent and automated operation of devices.
1、 Product Overview
Product model: 712-404561-00
Type: Processor Module
Brand: KLA Tencor
System: KLA Tencor 712 series detection/measurement platform
Functional positioning: Equipment core control and data processing platform
2、 Core functions
Function item description
The central processing unit is equipped with high-performance embedded CPUs or industrial grade processors, which execute complex control algorithms and task scheduling.
Real time data processing involves high-speed analysis and processing of data collected from image boards, sensor modules, scanning systems, and other units.
The system coordinates and controls the operation status of various sub modules of the entire machine, achieving motion control, optical control, data acquisition synchronization, etc.
The communication interface supports multiple industrial grade communication interfaces (such as Ethernet, RS-232/422/485, CAN, USB, PXI, etc.) to interact with other modules or upper level systems.
The software environment supports KLA specific operating systems or customized firmware, which can be upgraded and remotely managed.
3、 Application Fields
Wafer defect detection system
Implement defect recognition, image processing algorithms, and platform control strategies to achieve high-speed and high-precision wafer surface scanning and analysis.
Automatic optical metrology system
Control tasks such as laser measurement, morphology measurement, edge recognition, and real-time linkage with image systems.
Coordination between platform and scanning system
As the main control unit, it collaborates with servo drives, encoders, image systems, etc. to achieve stable and accurate measurement actions.
Data Collection and Transmission Center
Undertake real-time management and uploading of a large amount of image data, control data, and sensor signals.
2.产 品 展 示
