Novellus Systems 02-052474-00直流接线板
1.产 品 资 料 介 绍：
中文资料：
Novellus Systems 02-052474-00 直流接线板（DC Wiring Board） 是一款用于 Novellus 半导体制造设备内部的电源分配或信号接线功能的模块。它在系统中主要用于直流供电线路的整理、分布和接口连接，是设备电气系统中不可缺少的基础部件之一。
一、基本信息
产品名称：直流接线板（DC Wiring Board）
型号：02-052474-00
制造商：Novellus Systems Inc.（已并入 Lam Research）
应用领域：半导体设备的电源分配、信号接线与连接桥接
模块类型：背板类 / 接线端子板
二、功能说明
| 功能类别 | 描述 |
|---|---|
| 直流电源分配 | 提供多个电源输出端口，将主电源（如24V、48V等）分配到设备各子模块（如传感器、执行器、电磁阀、控制板等） |
| 信号整理 | 将来自主控或控制模块的低压信号通过统一接线方式分配给各执行组件 |
| 接地/屏蔽管理 | 提供良好的接地或屏蔽线连接通道，降低电磁干扰 |
| 安全隔离 | 某些版本可能集成过流保护、保险丝座等基础保护措施 |
三、典型应用位置
此接线板可能安装于以下设备或区域中：
Concept 系列 PECVD/SACVD/HDPCVD 系统的电源分配柜内
电气控制箱或设备后部接线区
工艺腔室附近的 I/O 接线集中点
与 DC 电源供应器（Power Supply）或继电器/保险丝模块配合使用
英文资料：
Novellus Systems 02-052474-00 DC Wiring Board is a module used for power distribution or signal wiring functions within Novellus semiconductor manufacturing equipment. It is mainly used in the system for the organization, distribution, and interface connection of DC power supply lines, and is one of the indispensable basic components in equipment electrical systems.
1、 Basic Information
Product Name: DC Wiring Board
Model: 02-052474-00
Manufacturer: Novellus Systems Inc. (merged into Lam Research)
Application areas: Power distribution, signal wiring, and bridging of semiconductor devices
Module Type: Backboard/Terminal Block
2、 Function Description
Functional category description
DC power distribution provides multiple power output ports, distributing the main power supply (such as 24V, 48V, etc.) to various sub modules of the equipment (such as sensors, actuators, solenoid valves, control boards, etc.)
Signal sorting distributes low-voltage signals from the main control or control module to each executing component through a unified wiring method
Grounding/shielding management provides a good grounding or shielding wire connection channel to reduce electromagnetic interference
Some versions of safety isolation may integrate basic protection measures such as overcurrent protection and fuse holders
3、 Typical application locations
This wiring board may be installed in the following devices or areas:
Inside the power distribution cabinet of the Concept series PECVD/SACVD/HDCPVD systems
Rear wiring area of electrical control box or equipment
Concentrated point of I/O wiring near the process chamber
Used in conjunction with DC power supply or relay/fuse modules
