TEL Tokyo Electron HTE-0C3-C-13连接器模块
1.产 品 资 料 介 绍：
中文资料：
TEL Tokyo Electron HTE-0C3-C-13 连接器模块 是东京电子（TEL）设备中用于电子信号连接和传输的重要组件，专门设计用于实现设备内部或模块间的电气连接，确保信号完整性和稳定性。
一、基本信息
产品名称：连接器模块（Connector Module）
产品型号：HTE-0C3-C-13
制造商：Tokyo Electron Ltd.（TEL）
类别：电子连接器模块
应用位置：设备内部电子模块连接点、机架间信号传输接口、控制柜模块间连接等
二、主要功能
模块间电气连接
提供标准化接口，连接不同电路板、模块或设备部件，保证电信号顺畅传输。
支持多通道信号传输，满足数字信号、模拟信号、电源线等多种信号类型。
信号完整性保护
采用高品质导体和接触结构，减少接触电阻和信号衰减，降低电磁干扰（EMI）。
可能带有屏蔽结构，增强抗干扰能力。
便捷安装与维护
设计符合模块化插拔要求，支持快速拆装，便于设备维护和更换。
结构紧凑，适应设备内部空间布局。
三、典型应用场景
| 应用部位 | 功能说明 |
|---|---|
| 控制柜内模块连接 | 连接主控板与I/O模块、传感器接口板等，实现信号和电源传输 |
| 机架间信号线 | 实现多模块间高速数据和控制信号传输 |
| 现场设备接口 | 连接传感器、执行器模块，保证可靠通讯 |
英文资料：
The TEL Tokyo Electron HTE-0C3-C-13 connector module is an important component used for electronic signal connection and transmission in Tokyo Electronics (TEL) equipment. It is specifically designed to achieve electrical connections within the equipment or between modules, ensuring signal integrity and stability.
1、 Basic Information
Product Name: Connector Module
Product Model: HTE-0C3-C-13
Manufacturer: Tokyo Electron Ltd. (TEL)
Category: Electronic connector module
Application locations: internal electronic module connection points, inter rack signal transmission interfaces, control cabinet module connections, etc
2、 Main functions
Electrical connection between modules
Provide standardized interfaces to connect different circuit boards, modules, or device components, ensuring smooth transmission of electrical signals.
Supports multi-channel signal transmission, meeting various signal types such as digital signals, analog signals, power lines, etc.
Signal integrity protection
Using high-quality conductors and contact structures to reduce contact resistance and signal attenuation, and lower electromagnetic interference (EMI).
It may have a shielding structure to enhance anti-interference ability.
Convenient installation and maintenance
The design meets the requirements of modular plugging and unplugging, supports quick disassembly and assembly, and facilitates equipment maintenance and replacement.
Compact structure, suitable for internal space layout of equipment.
3、 Typical application scenarios
Function Description of Application Parts
Connect the modules inside the control cabinet to the main control board, I/O modules, sensor interface boards, etc., to achieve signal and power transmission
Inter rack signal lines enable high-speed data and control signal transmission between multiple modules
On site equipment interfaces are connected to sensor and actuator modules to ensure reliable communication
