TEL Tokyo Electron 2L81-050032-V2处理器板
1.产 品 资 料 介 绍：
中文资料：
产品型号：2L81-050032-V2
产品名称：处理器板（Processor Board）
制造商：Tokyo Electron Ltd.（TEL）
部件类别：嵌入式控制处理单元 / 核心处理模块
一、产品概述：
2L81-050032-V2 是 Tokyo Electron 半导体设备中使用的一款 处理器板卡，负责执行设备内部的控制逻辑计算、数据处理、指令调度和系统通讯等关键任务。
该板卡通常搭载嵌入式CPU或微控制器，作为设备控制系统的“大脑”，承担多任务调度及实时控制要求，确保设备工艺流程的精确运行。
二、主要功能：
| 功能模块 | 说明 |
|---|---|
| 控制指令处理 | 解析和执行工艺控制程序指令 |
| 数据采集管理 | 处理来自传感器和输入模块的采样数据 |
| 输出控制 | 控制执行模块的动作指令输出 |
| 通信协调 | 与上位控制系统及内部各模块进行通讯 |
| 运行监测 | 监控系统运行状态，检测异常报警 |
三、技术参数（参考通用TEL处理器板设计）：
| 项目 | 典型参数或说明 |
|---|---|
| 处理器类型 | 嵌入式CPU/MCU（如ARM架构或TEL定制芯片） |
| 存储器 | 内置Flash、RAM用于程序及数据存储 |
| 输入接口 | 支持数字量/模拟量输入，含传感器信号 |
| 输出接口 | 支持多路DO、模拟输出及PWM控制信号 |
| 通信协议 | 支持RS232、RS485、CAN、Ethernet或TEL专有协议 |
| 电源需求 | 常见24V DC供电，支持电源管理 |
| 安装形式 | 插卡式或机架式安装，方便维护更换 |
英文资料：
Product model: 2L81-050032-V2
Product Name: Processor Board
Manufacturer: Tokyo Electron Ltd. (TEL)
Component Category: Embedded Control Processing Unit/Core Processing Module
1、 Product Overview:
2L81-050032-V2 is a processor board used in Tokyo Electron semiconductor equipment, responsible for executing key tasks such as internal control logic calculations, data processing, instruction scheduling, and system communication.
This board is usually equipped with an embedded CPU or microcontroller, serving as the "brain" of the device control system, responsible for multitasking scheduling and real-time control requirements, ensuring the precise operation of the equipment process flow.
2、 Main functions:
Function module description
Control instruction processing, parsing, and execution of process control program instructions
Data collection management processes sampled data from sensors and input modules
Output control execution module's action command output
Communication coordination and communication with the upper control system and internal modules
Running monitoring and monitoring system operation status, detecting abnormal alarms
3、 Technical parameters (refer to the design of a general TEL processor board):
Typical parameters or descriptions of the project
Processor type: Embedded CPU/MCU (such as ARM architecture or TEL custom chip)
Memory with built-in Flash and RAM for program and data storage
The input interface supports digital/analog input, including sensor signals
The output interface supports multiple DO, analog outputs, and PWM control signals
The communication protocol supports RS232, RS485, CAN, Ethernet, or TEL proprietary protocols
Common power requirements include 24V DC power supply and support for power management
Installation form: plug-in or rack mounted, convenient for maintenance and replacement
