UNIOP ETOP507U3P1触摸屏
1.产 品 资 料 介 绍：
一、产品名称
UNIOP ETOP507U3P1 触摸屏
二、产品概述
ETOP507U3P1 是一款5.7英寸彩色触摸屏面板，具备高分辨率和丰富的通讯接口，支持多种工业协议，适合嵌入式和本地操作环境，具备良好的图形表现力和操作灵敏度。
三、技术规格
| 参数 | 说明 |
|---|---|
| 显示屏 | 5.7英寸 TFT 彩色 LCD |
| 分辨率 | 320 × 240 像素（QVGA） |
| 触摸方式 | 电阻式单点触摸 |
| 显示颜色 | 65,536 色 |
| 处理器 | ARM Cortex-A8 或类似性能的嵌入式处理器 |
| 存储 | 128MB Flash，64MB RAM |
| 通讯接口 | RS232，RS485，USB Host，Ethernet (视具体配置) |
| 电源输入 | 24V DC（通常范围18-30V） |
| 操作系统 | 嵌入式 Linux |
| 防护等级 | 前面板 IP65 |
| 工作温度范围 | 0°C 至 +50°C |
| 软件开发工具 | 支持 JMobile Studio 软件开发环境 |
四、主要功能
图形用户界面：支持多画面显示、动画、报警和趋势曲线
通讯协议支持：Modbus RTU/TCP、西门子 S7、Allen-Bradley、Mitsubishi 等
数据记录与报警管理：具备报警记录、事件日志及配方管理
远程维护：支持远程下载、诊断和监控
多语言支持：界面可切换多种语言，适合国际化应用
英文资料：
1、 Product Name
UNIOP ETOP507U3P1 touch screen
2、 Product Overview
ETOP507U3P1 is a 5.7-inch color touch screen panel with high resolution and rich communication interfaces. It supports multiple industrial protocols and is suitable for embedded and local operating environments. It has good graphic performance and operational sensitivity.
3、 Technical specifications
Parameter Description
Display screen 5.7-inch TFT color LCD
Resolution 320 × 240 pixels (QVGA)
Touch method: resistive single point touch
Display color 65536 colors
ARM Cortex-A8 or similar performance embedded processors
Store 128MB Flash and 64MB RAM
Communication interfaces RS232, RS485, USB Host, Ethernet (depending on specific configuration)
Power input 24V DC (usually ranging from 18-30V)
Operating System Embedded Linux
Protection level front panel IP65
Working temperature range: 0 ° C to+50 ° C
Software development tools support JMobile Studio software development environment
4、 Main functions
Graphic user interface: supports multi screen display, animation, alarm, and trend curve
Communication protocol support: Modbus RTU/TCP, Siemens S7, Allen Bradley, Mitsubishi, etc
Data recording and alarm management: equipped with alarm recording, event logs, and recipe management
Remote maintenance: supports remote downloading, diagnosis, and monitoring
Multi language support: The interface can switch between multiple languages, suitable for international applications
2.产 品 展 示
