UNIOP ETOP504U3P1 操作面板
1.产 品 资 料 介 绍：
UniOP ETOP504U3P1 操作面板简介
一、产品概述
ETOP504U3P1 是 UniOP eTOP 系列的一款工业级人机界面（HMI）操作面板，配备 4.3 英寸彩色宽屏显示器，支持电阻式触摸功能，适用于多种自动化应用场景。
二、主要技术参数
显示屏尺寸：4.3 英寸 TFT 彩色液晶
分辨率：480 × 272 像素（16:9 宽屏）
触控方式：电阻式触摸屏
内存：128MB Flash，256MB RAM
通信接口：RS-232、RS-422/485、双以太网接口、USB 主从口、SD 卡插槽
电源输入：24V DC
安装方式：面板嵌入式
软件支持：兼容 JMobile Studio 平台，支持图形化界面设计、宏命令、报警、趋势、配方、多语言支持等功能
三、典型应用领域
工业自动化设备控制
用于机械设备、人机界面显示、参数调整和报警信息监控。楼宇与能源管理系统
应用于空调、电梯、水泵等系统操作界面。过程监控与数据管理
提供历史数据记录、趋势分析、配方切换等功能，便于操作与追溯。替代旧型号与维修用途
用作早期 eTOP 小尺寸面板的替代，适合旧设备升级与维护。
英文资料：
Introduction to UniOP ETOP504U3P1 Operation Panel
1、 Product Overview
ETOP504U3P1 is an industrial grade human-machine interface (HMI) control panel in the UniOP eTOP series, equipped with a 4.3-inch color widescreen display, supporting resistive touch function, and suitable for various automation application scenarios.
2、 Main technical parameters
Display screen size: 4.3-inch TFT color LCD
Resolution: 480 × 272 pixels (16:9 widescreen)
Touch mode: resistive touch screen
Memory: 128MB Flash, 256MB RAM
Communication interface: RS-232, RS-422/485, dual Ethernet interface, USB master-slave port, SD card slot
Power input: 24V DC
Installation method: panel embedded
Software support: compatible with JMobile Studio platform, supporting graphical interface design, macro commands, alarms, trends, formulas, multilingual support and other functions
3、 Typical application areas
Industrial automation equipment control
Used for mechanical equipment, human-machine interface display, parameter adjustment, and alarm information monitoring.
Building and Energy Management System
Applied to the operation interface of systems such as air conditioning, elevators, and water pumps.
Process monitoring and data management
Provide functions such as historical data recording, trend analysis, and formula switching for easy operation and traceability.
ｒｅｐｌａｃｅ old models and repair purposes
Used as a replacement for early eTOP small-sized panels, suitable for upgrading and maintaining old devices.
