UNIOP ETOP507U2P3触摸屏面板
1.产 品 资 料 介 绍：
UniOP eTOP507U2P3 触摸屏面板简介
一、产品概述
eTOP507U2P3 属于 UniOP eTOP 500 系列，是一款工业级人机界面（HMI）触摸触控面板。搭载 7 英寸彩色宽屏显示，设计用于复杂的工业自动化应用场景。
二、主要技术参数
显示屏：7 英寸 TFT 彩色宽屏（16:9），分辨率 800×480 像素
触控方式：电阻式电容混合触摸或电阻式触摸（视具体批次而定）
内存：256 MB RAM，128 MB Flash，可运行复杂界面和脚本
通信接口：双以太网（10/100 Mbps）、USB 主机端口、USB 设备端口、SD 卡插槽
扩展支持：可使用可插拔模块（如 Profibus、CANopen、DeviceNet）扩展现场总线功能
电源输入：24 V DC
环境适应：支持 IP65 前面板防护，耐尘防水；工作温度范围一般为 0–50 °C
软件支持：兼容 JMobile 平台，具备矢量图形、报警历史、趋势绘图、配方管理、多语言配置、宏命令等高级功能
三、典型应用场景
制造业自动化现场操作与监控
过程控制系统中的实时数据展示与设备设置
设备报警、趋势记录与报表功能应用
楼宇自动化系统中的暖通与配电控制
集中控制架构中多装置互联（借助 UniNet 或 OPC Server）
英文资料：
Introduction to UniOP eTOP507U2P3 Touch Screen Panel
1、 Product Overview
ETOP507U2P3 belongs to the UniOP eTOP 500 series and is an industrial grade human-machine interface (HMI) touch panel. Equipped with a 7-inch color widescreen display, designed for complex industrial automation application scenarios.
2、 Main technical parameters
Display screen: 7-inch TFT color widescreen (16:9), resolution 800 × 480 pixels
Touch mode: resistive capacitive hybrid touch or resistive touch (depending on the specific batch)
Memory: 256 MB RAM, 128 MB Flash, capable of running complex interfaces and scripts
Communication interface: Dual Ethernet (10/100 Mbps), USB host port, USB device port, SD card slot
Extended support: Can use pluggable modules (such as Profibus, CANopen, DeviceNet) to expand fieldbus functionality
Power input: 24V DC
Environmental adaptation: Supports IP65 front panel protection, dust and water resistance; The working temperature range is generally 0-50 ° C
Software support: compatible with JMobile platform, with advanced functions such as vector graphics, alarm history, trend drawing, recipe management, multilingual configuration, macro commands, etc
3、 Typical application scenarios
Manufacturing automation on-site operation and monitoring
Real time data display and equipment settings in process control systems
Application of device alarm, trend recording and reporting functions
HVAC and Distribution Control in Building Automation Systems
Multi device interconnection in centralized control architecture (using UniNet or OPC Server)
2.产 品 展 示
