KEBA E-10-ANALOG-SU 印刷电路板
1.产 品 资 料 介 绍：
一、产品概述
KEBA E-10-ANALOG-SU 是一款用于工业自动化系统的 模拟信号输入/输出（I/O）扩展 PCB 模块。该模块设计用于 KEBA 控制平台，为主控制系统提供高精度的模拟量采集与输出能力。它广泛应用于温度控制、压力监测、速度调节等需要模拟信号处理的自动化场景中，是系统实现精密控制的重要组成部分。
二、技术参数
型号：E-10-ANALOG-SU
功能类型：模拟信号输入/输出电路板
输入类型：多路模拟输入，支持 0–10V 或 4–20mA（依据配置）
输出类型：模拟输出通道，适配标准模拟执行器
精度等级：高分辨率 A/D 和 D/A 转换模块，适用于精密控制
供电电压：通常为 24V DC
通信接口：通过总线连接至主控制器，可能支持 CAN、EtherCAT 或内部扩展接口
安装方式：插槽式或螺丝固定安装
工作环境：适用于 -10°C 至 +60°C 工业环境，具备抗电磁干扰设计
三、应用领域
温度控制系统
用于接收热电偶、热电阻等模拟信号，实现精准温控调节。
压力与流量监测设备
接入压力传感器/流量计等现场设备，进行信号转换与反馈控制。
伺服与驱动系统
提供模拟速度控制、电流调节等输出，适用于精密运动控制设备。
注塑、包装、印刷机械
处理来自现场模拟传感器的输入信号，实现动态控制调节。
英文资料：
1、 Product Overview
KEBA E-10-ANALOG-SU is an analog signal input/output (I/O) expansion PCB module for industrial automation systems. This module is designed for the KEBA control platform to provide high-precision analog acquisition and output capabilities for the main control system. It is widely used in automation scenarios that require analog signal processing, such as temperature control, pressure monitoring, and speed regulation, and is an important component of achieving precision control in the system.
2、 Technical parameters
Model: E-10-ANALOG-SU
Function type: Analog signal input/output circuit board
Input type: Multi channel analog input, supporting 0-10V or 4-20mA (depending on configuration)
Output type: Analog output channel, compatible with standard analog actuators
Accuracy level: High resolution A/D and D/A conversion module, suitable for precision control
Power supply voltage: usually 24V DC
Communication interface: Connected to the main controller through a bus, may support CAN, EtherCAT, or internal expansion interfaces
Installation method: slot type or screw fixed installation
Working environment: Suitable for industrial environments ranging from -10 ° C to+60 ° C, with anti electromagnetic interference design
3、 Application Fields
Temperature controller
Used to receive analog signals from thermocouples, thermal resistors, etc., to achieve precise temperature control adjustment.
Pressure and flow monitoring equipment
Connect pressure sensors/flow meters and other on-site equipment for signal conversion and feedback control.
Servo and Drive System
Provide outputs such as analog speed control and current regulation, suitable for precision motion control equipment.
Injection molding, packaging, and printing machinery
Process input signals from on-site simulated sensors to achieve dynamic control and adjustment.
2.产 品 展 示
