KEBA HT2/SS/20677机器人示教器

 KEBA HT2/SS/20677机器人示教器

1.产 品 资 料 介 绍：

KEBA HT2/SS/20677 是 KEBA 公司推出的 HT2 系列机器人示教器 的特定版本，具备手持式人机交互能力，用于工业机器人或自动化设备的编程、控制与监控。它集成触摸屏、人机操作按钮、急停开关和现场通信接口，使操作者能够直接在现场以可视化方式操作或调试机器人程序。该型号常见于自动化装配、注塑上下料、包装线、搬运等场景。

二、技术参数

• 型号：HT2/SS/20677

• 产品类型：手持式机器人示教器（Handheld Teach Pendant）

• 显示屏：TFT 彩色触摸屏（尺寸多为 7" 或 10"），高分辨率

• 操作按键：

  • 多功能软键、方向键、功能快捷键

  • 含启动、停止、急停、选择模式等机械按钮

• 急停按钮：一体集成式，符合 EN ISO 13850 安全标准

• 连接方式：工业专用数据电缆（RJ45、D-sub、M12 或 KEBA 专用接口）

• 外壳材质：高强度工业塑料，具备抗摔与防尘性能

• 人机交互：图形化菜单界面，支持手动/自动切换、轴控制等

• 工作电压：由主控系统供电（通常为 24V DC）

• 防护等级：IP54（适用于工业环境）

• 认证标准：CE、UL（依据具体版本）

三、应用领域

1. 工业机器人编程与示教

   • 手动控制机器人动作、记录示教路径、执行调试程序。

2. 注塑上下料系统调试

   • 用于控制机械臂抓取、移动、放置等精确动作过程。

3. 柔性自动化生产线控制

   • 控制与管理搬运、焊接、包装等工作站的机器人模块。

4. OEM 特种设备定制控制终端

   • 可根据客户定制界面与功能，嵌入到自动化系统作为便携操控终端。

英文资料：

KEBA HT2/SS/20677 is a specific version of the HT2 series robot teaching pendant launched by KEBA, which has handheld human-machine interaction capabilities and is used for programming, control, and monitoring of industrial robots or automation equipment. It integrates a touch screen, human-machine operation buttons, emergency stop switch, and on-site communication interface, allowing operators to directly operate or debug robot programs in a visual manner on site. This model is commonly used in scenarios such as automated assembly, injection molding loading and unloading, packaging lines, and handling.

2、 Technical parameters

Model: HT2/SS/20677

Product Type: Handheld Teach Pendant

Display screen: TFT color touch screen (mostly 7 "or 10" in size), high resolution

Operation buttons:

Multi functional soft keys, directional keys, functional shortcut keys

Including mechanical buttons such as start, stop, emergency stop, and mode selection

Emergency stop button: integrated and compliant with EN ISO 13850 safety standards

Connection method: Industrial dedicated data cable (RJ45, D-sub, M12 or KEBA dedicated interface)

Shell material: high-strength industrial plastic, with anti ｄｒｏｐ and dust-proof properties

Human computer interaction: graphical menu interface, supporting manual/automatic switching, axis control, etc

Working voltage: Powered by the main control system (usually 24V DC)

Protection level: IP54 (suitable for industrial environments)

Certification standards: CE, UL (depending on specific version)

3、 Application Fields

Industrial Robot Programming and Demonstration

Manually control robot actions, record teaching paths, and execute debugging programs.

Debugging of injection molding loading and unloading system

Used to control precise movements such as grasping, moving, and placing of robotic arms.

Flexible automation production line control

Robot modules for controlling and managing workstations such as handling, welding, and packaging.

OEM special equipment customized control terminal

Customized interfaces and functions can be embedded into automation systems as portable control terminals based on customer needs.

2.产      品      展      示
