KEBA E-16-DIGOUT-P数字输出板
1.产 品 资 料 介 绍：
产品概述
KEBA E-16-DIGOUT-PL 是一款高性能的 数字输出模块，专为 KEBA 自动化系统（如 KeControl、KePlast 等平台）设计，用于控制各种外部数字设备，如电磁阀、继电器、马达控制器、指示灯等执行机构。该模块提供 16 路隔离型数字输出通道，具备快速响应、高可靠性和工业级抗干扰能力，适合部署在复杂的工业自动化控制环境中。
技术参数
产品型号：E-16-DIGOUT-PL
模块类型：数字量输出模块（Digital Output Module）
输出通道数：16 路独立数字输出
输出类型：
24V DC 开路集电极输出（一般为 PNP 型，具体以实物标签为准）
每通道最大输出电流：0.5 A
模块总电流承载能力：最多 8 A
输出保护功能：
短路保护
过载保护
热保护
电气隔离：输出与逻辑部分光电隔离
状态指示灯：每路输出具备 LED 状态指示
接口类型：标准接线端子或插接式连接器
电源电压：24V DC ±20%
安装方式：DIN 导轨安装
工作温度范围：-10°C ～ +60°C
英文资料：
product overview
KEBA E-16-DIGOUT-PL is a high-performance digital output module designed specifically for KEBA automation systems (such as KeControl, KePlast, etc.), used to control various external digital devices such as solenoid valves, relays, motor controllers, indicator lights, and other actuators. This module provides 16 isolated digital output channels, with fast response, high reliability, and industrial grade anti-interference capabilities, suitable for deployment in complex industrial automation control environments.
Technical Parameter
Product model: E-16-DIGOUT-PL
Module type: Digital Output Module
Number of output channels: 16 independent digital outputs
Output type:
24V DC open collector output (generally PNP type, subject to physical label)
Maximum output current per channel: 0.5 A
Module total current carrying capacity: up to 8 A
Output protection function:
Short circuit protection
overload protection
Thermal
Electrical isolation: photoelectric isolation between output and logic parts
Status indicator light: Each output has LED status indication
Interface type: standard terminal block or plug-in connector
Power supply voltage: 24V DC ± 20%
Installation method: DIN rail installation
Working temperature range: -10 ° C to+60 ° C
2.产 品 展 示
