Atlas Copco PF3107-G-HW驱动装置
1.产 品 资 料 介 绍：
Atlas Copco PF3107-G-HW 驱动装置
（Power Focus 3100 系列）
产品概述：
PF3107-G-HW 是 Atlas Copco Power Focus 3100 系列中的一款驱动装置，专为控制单把电动拧紧工具而设计，适用于基本工业装配环境。该型号具备稳定的拧紧控制功能，并支持数据采集与现场总线通信，满足中等复杂度生产线的控制需求。
型号说明：
PF3107：Power Focus 3100 型号，适用于单工具控制
G：代表“通用”（General）用途，具备标准控制与通信功能
HW：硬件授权版本（非软件激活），通过硬件方式启用功能
核心功能：
控制 Atlas Copco Tensor 系列工具（如 ST、SR）
精确执行扭矩、角度控制和多种拧紧策略
本地数据采集和追溯功能
工艺参数存储、错误监控和报警功能
可与 PLC 或 MES 系统通讯集成
通信接口与支持协议：
标配有以太网接口
支持 Open Protocol 通信协议
可选适配 DeviceNet、Profibus、Profinet 等（视具体配置）
应用领域：
电子产品与电气设备装配
家电制造
汽车零部件小型工位拧紧任务
中小型装配生产线
需要稳定扭矩控制但对数据处理要求适中的工业应用
产品特点：
结构紧凑，便于集成安装
稳定可靠，适应多种工业环境
控制精度高，调试简单
支持常用通讯协议，便于集成到现有产线
可与 Atlas Copco 标准工具快速匹配使用
英文资料：
Atlas Copco PF3107-G-HW Drive Device
(Power Focus 3100 series)
Product Overview:
PF3107-G-HW is a drive device in the Atlas Copco Power Focus 3100 series, designed specifically for controlling single handle electric tightening tools and suitable for basic industrial assembly environments. This model has stable tightening control function and supports data acquisition and fieldbus communication, meeting the control requirements of medium complexity production lines.
Model Description:
PF3107: Power Focus 3100 model, suitable for single tool control
G: Represents' General 'use, with standard control and communication functions
HW: Hardware authorized version (non software activated), enabling functionality through hardware means
Core functions:
Control Atlas Copco Tensor series tools (such as ST, SR)
Accurate execution of torque, angle control, and multiple tightening strategies
Local data collection and traceability function
Process parameter storage, error monitoring, and alarm functions
Can communicate and integrate with PLC or MES systems
Communication interface and supporting protocols:
Equipped with Ethernet interface as standard
Support Open Protocol communication protocol
Optional compatibility with DeviceNet, Profibus, Profinet, etc. (depending on specific configuration)
Application areas:
Assembly of electronic products and electrical equipment
Home appliance manufacturing
Tightening task for small workstations of automotive parts
Small and medium-sized assembly production line
Industrial applications that require stable torque control but moderate data processing requirements
Product features:
Compact structure, easy to integrate and install
Stable and reliable, adaptable to various industrial environments
High control accuracy and simple debugging
Support common communication protocols for easy integration into existing production lines
Can be quickly matched and used with Atlas Copco standard tools
2.产 品 展 示
