1.产 品 资 料 介 绍：

一、产品概述

Atlas Copco PF3102-C-HW 是 Power Focus 3100 系列控制器中的一员，用于控制 Atlas Copco Tensor 系列电动拧紧工具，执行高精度的扭矩和角度控制任务。该型号以紧凑型结构为特点，适合嵌入式安装，尤其适用于需要节省空间或分布式控制的自动化产线。

型号说明：

• PF3102：表示控制器为 PF3100 系列的 2 通道标准型号

• C：标准配置，具备核心控制与通信功能

• HW：指硬件版本（Hardware）

二、技术参数

• 适配工具：支持 Tensor ST、SL、STR、EBL、ETX 等系列拧紧工具

• 控制功能：扭矩控制、角度控制、多阶段控制、自适应控制

• 电源输入：AC 100–240V，50/60Hz

• 通信接口：Ethernet、RS232、数字 I/O（也可选配 Profinet、DeviceNet、EtherNet/IP 等）

• 程序容量：支持多达 255 个拧紧程序

• 过程数据：支持每次拧紧的数据记录、曲线存储、实时传输

• 用户接口：支持外接显示器、触摸屏、操作面板或通过 PC 使用 ToolsTalk PF 工具配置

英文资料：

1、 Product Overview

Atlas Copco PF3102-C-HW is a member of the Power Focus 3100 series controller, used to control Atlas Copco Tensor series electric tightening tools and perform high-precision torque and angle control tasks. This model is characterized by a compact structure, suitable for embedded installation, especially for automated production lines that require space saving or distributed control.

Model Description:

PF3102: Indicates that the controller is a 2-channel standard model of the PF3100 series

C: Standard configuration with core control and communication functions

HW: Refers to the hardware version (Hardware)

2、 Technical parameters

Adaptation tool: Supports tightening tools such as Tensor ST, SL, STR, EBL, ETX, and other series

Control functions: torque control, angle control, multi-stage control, adaptive control

Power input: AC 100-240V, 50/60Hz

Communication interfaces: Ethernet, RS232, digital I/O (optional Profinet, DeviceNet, EtherNet/IP, etc.)

Program capacity: Supports up to 255 tightening programs

Process data: supports data recording for each tightening, curve storage, and real-time transmission

User Interface: Supports external display, touch screen, operation panel, or configuration using ToolsTalk PF tool through PC
