GIDINGS&LEWIS 502-03518-03模拟输出模块

 GIDINGS&LEWIS  502-03518-03模拟输出模块

1.产 品 资 料 介 绍：

产品概述

技术参数

1. 通道配置：搭载 8 路独立模拟输出通道，可同时满足多设备信号驱动需求
2. 输出电压范围：标称 ±10V DC，实际工作范围可达 ±11V DC，适配多数工业执行装置电压需求
3. 信号分辨率：16 位高精度分辨率，对应 65,536 个调节步进，确保信号输出的细腻度与精准度
4. 输出电流能力：最大输出电流为 ±10mA，可稳定驱动各类负载设备
5. 信号更新效率：输出更新间隔仅 32µs，快速响应控制指令，保障系统动态调节性能
6. 输出精度：在 ±11V 工作范围内，输出精度控制在 ±5% 以内，满足工业级精度标准
7. 复位机制：具备上电自动复位与通信中断复位功能，复位后输出电压稳定在 0V（误差范围 ±20mV），避免设备异常运行
8. 信号稳定性：输出纹波小于 10mV RMS（测试频率 30kHz），有效降低信号干扰，保障设备稳定运行
9. 保护功能：内置短路电流限制保护模块，当输出端发生短路时，可快速限制电流，保护模块与后端设备免受损坏

英文资料：

Product Overview

As an important component of the PiC900 control system family, the Giddings&Lewis 502-03518-03 analog output module is responsible for the core task of converting digital control signals into high-precision voltage analog signals. Its core value lies in providing stable driving signals for servo systems, process control links, and various industrial automation execution equipment. With multi-channel output design and excellent performance, it can easily adapt to industrial application scenarios with high requirements for signal accuracy and response speed, providing reliable support for the precise operation of automated production processes.

Technical Specifications

Channel configuration: Equipped with 8 independent analog output channels, it can simultaneously meet the signal driving requirements of multiple devices

Output voltage range: nominal ± 10V DC, actual working range can reach ± 11V DC, suitable for the voltage requirements of most industrial execution devices

Signal resolution: 16 bit high-precision resolution, corresponding to 65536 adjustment steps, ensuring the delicacy and accuracy of signal output

Output current capability: The maximum output current is ± 10mA, which can stably drive various load devices

Signal ｕｐｄａｔｅ efficiency: The output ｕｐｄａｔｅ interval is only 32 µ s, which quickly responds to control instructions and ensures the dynamic adjustment performance of the system

Output accuracy: Within the working range of ± 11V, the output accuracy is controlled within ± 5%, meeting the industrial grade accuracy standard

Reset mechanism: It has the functions of automatic power on reset and communication interruption reset. After reset, the output voltage stabilizes at 0V (error range ± 20mV) to avoid abnormal operation of the equipment

Signal stability: The output ripple is less than 10mV RMS (test frequency 30kHz), effectively reducing signal interference and ensuring stable operation of the equipment

Protection function: Built in short-circuit current limiting protection module, which can quickly limit the current when a short circuit occurs at the output terminal, protecting the module and backend equipment from damage

2.产      品      展      示
