IC697MDL753逻辑控制器模块

IC697MDL753逻辑控制器模块

1.产 品 资 料 介 绍：

一、核心定位与关键特性

1. 模块类型：32 点数字量输出，负逻辑驱动，两组 16 点电气隔离，属 Series 90-70 系统高可靠离散量输出模块。
2. 双电压适配：5 VDC 时每点 16 mA，兼容 TTL 逻辑接口；10–60 VDC 时每点 0.5 A，适配主流直流执行机构。
3. 浪涌承载：最大 5 A/20 ms 浪涌电流，可直接驱动含线圈的感性负载，无需额外缓冲电路。
4. 高速响应：导通与关断响应时间均≤1 ms，满足高频启停与快速顺序控制需求。
5. 热设计与保护：每组最大 4 A 总电流，输出压降典型值 1 V@2 Ω，有效控制温升；具备分组隔离与 LED 逐点状态指示，便于调试与故障定位。
6. 配置便捷：无需跳线或 DIP 开关，通过系统软件完成 I/O 映射，适配工业网络配置环境。

二、技术规格（关键参数）

• 所属系列：GE Fanuc Series 90-70
• 输出点数：32 点（2 组 ×16 点，分组隔离）
• 额定电压：5 VDC 或 10–60 VDC
• 输出电流：5 VDC 时 16 mA / 点；10–60 VDC 时 0.5 A / 点，4 A / 组
• 浪涌电流：5 A/20 ms（最大值）
• 响应时间：≤1 ms（ON/OFF）
• 逻辑类型：负逻辑（低电平有效）
• 指示：每点独立 LED 状态灯
• 典型压降：1 V（最大，2 Ω）

三、应用领域

IC697MDL753逻辑控制器模块 英文资料：

IC697MDL753 is a 32 point DC negative logic output module of GE Fanuc Series 90-70 series. It adopts two sets of 16 point group isolation design, supports 5 VDC TTL level and 10-60 VDC industrial load dual voltage mode, with a single continuous current of 0.5 A and 5 A/20 ms surge capability. It is suitable for driving various loads such as solenoid valves, contactors, indicator lights, and TTL interfaces.

1、 Core positioning and key characteristics

Module type: 32-bit digital output, negative logic drive, two sets of 16 point electrical isolation, belonging to Series 90-70 system high reliability discrete output module.

Dual voltage adaptation: 16 mA per point at 5 VDC, compatible with TTL logic interface; 0.5 A per point at 10-60 VDC, compatible with mainstream DC actuators.

Surge carrying capacity: Maximum surge current of 5 A/20 ms, can directly drive inductive loads with coils without the need for additional buffering circuits.

High speed response: Both on and off response times are ≤ 1 ms, meeting the requirements of high-frequency start stop and fast sequential control.

Thermal design and protection: Each group has a maximum total current of 4 A, with a typical output voltage ｄｒｏｐ of 1 V @ 2 Ω, effectively controlling temperature rise; Equipped with group isolation and LED point by point status indication for easy debugging and fault location.

Convenient configuration: No need for jumpers or DIP switches, I/O mapping can be completed through system software to adapt to industrial network configuration environments.

2、 Technical specifications (key parameters)

Series: GE Fanuc Series 90-70

Output points: 32 points (2 groups x 16 points, isolated groups)

Rated voltage: 5 VDC or 10-60 VDC

Output current: 16 mA/point at 5 VDC; 0.5 A/point, 4 A/group at 10-60 VDC

Surge current: 5 A/20 ms (maximum)

Response time: ≤ 1 ms (ON/OFF)

Logic type: Negative logic (low level valid)

Indication: Independent LED status lights for each point

Typical voltage ｄｒｏｐ: 1 V (maximum, 2 Ω)

3、 Application Fields

This module is widely used in fields such as automotive manufacturing, material handling, packaging machinery, process control, and power automation. It is suitable for driving relays, contactors, small motor starters, solenoid valves, indicator lights, and other loads. It is particularly suitable for industrial scenarios that require direct adaptation to TTL levels and wide range DC loads, as well as requirements for surge capability and response speed.
