PROTECH SYSTEMS PBI-6SA印刷电路板

PROTECH SYSTEMS PBI-6SA印刷电路板

1.产 品 资 料 介 绍：

一、核心定位与功能

1. 6 通道振动输入：可同时监测 6 个测点的振动信号，覆盖多轴承 / 多机组监测场景。
2. 实时监测 + 多级保护：内置振动幅值 / 烈度计算，支持报警 + 危险两级继电器输出，超限自动触发停机或联锁。
3. 工业级防护：前面板达 NEMA 4X / IP66，防尘防水防腐蚀，适配化工厂、电厂、冶金等恶劣现场。
4. 宽压供电：兼容多规格直流 / 交流输入，适配全球工业电网环境。
5. 双安装方式：支持面板嵌入式安装与 DIN 导轨安装，灵活集成于控制柜。
6. 状态可视化：板载 LED 指示灯，实时显示通道状态、报警 / 危险、电源与通讯状态。
7. 信号调理与隔离：内置信号放大、滤波、电气隔离，抗现场电磁干扰，保证测量精度。
8. 继电器输出：提供多组干接点输出，可直接接入 PLC/DCS 或驱动声光报警、停机回路。
9. 宽温稳定运行：工作温度 -40℃～+85℃，满足极端工况下长期可靠运行。
10. 低功耗设计：典型功耗约 2W，适合密集安装的控制柜散热环境。
11. 尺寸紧凑：体积小巧（约 22.5×16.5×10mm），节省柜内空间。
12. 标准化接口：端子式接线，布线规范，便于现场安装与维护。
13. 兼容主流系统：可无缝接入 Foxboro、Triconex、ABB 等 DCS/PLC 平台，作为独立保护单元或系统扩展模块。
14. 长寿命元器件：工业级器件选型，支持 7×24 小时连续运行，降低维护频率。
15. 应用场景：广泛用于电厂汽轮机、石化压缩机、冶金风机、水厂泵组等旋转机械的振动安全保护。

PROTECH SYSTEMS PBI-6SA印刷电路板 英文资料：

PBI-6SA is a 6-channel vibration monitoring and protection PCB module designed by PROTECH SYSTEMS specifically for rotating machinery. Its core is used for vibration over limit warning and shutdown protection of key equipment such as steam turbines, compressors, pumps, and fans. It is an important safety monitoring unit in industrial DCS/PLC systems.

1、 Core positioning and functions

6-channel vibration input: can simultaneously monitor the vibration signals of 6 measuring points, covering multiple bearing/multi unit monitoring scenarios.

Real time monitoring+multi-level protection: Built in vibration amplitude/intensity calculation, supports alarm and danger two-level relay output, automatically triggers shutdown or interlocking when exceeding the limit.

Industrial grade protection: The front panel is NEMA 4X/IP66, dustproof, waterproof, and corrosion-resistant, suitable for harsh environments such as chemical plants, power plants, and metallurgy.

Wide voltage power supply: compatible with multiple specifications of DC/AC inputs, suitable for global industrial power grid environments.

Dual installation method: Supports panel embedded installation and DIN rail installation, flexibly integrated into the control cabinet.

Status visualization: onboard LED indicator lights, real-time display of channel status, alarm/danger, power and communication status.

Signal conditioning and isolation: Built in signal amplification, filtering, electrical isolation, resistant to on-site electromagnetic interference, ensuring measurement accuracy.

Relay output: Provides multiple sets of dry contact outputs, which can be directly connected to PLC/DCS or drive sound and light alarm and shutdown circuits.

Wide temperature stable operation: Operating temperature range of -40 ℃ to+85 ℃, meeting long-term reliable operation under extreme working conditions.

Low power design: Typical power consumption is about 2W, suitable for densely installed control cabinet cooling environments.

Compact size: Small in size (approximately 22.5 × 16.5 × 10mm), saving space inside the cabinet.

Standardized interface: terminal wiring, wiring specifications, easy to install and maintain on site.

Compatible with mainstream systems: It can seamlessly integrate with DCS/PLC platforms such as Foxboro, Triconex, ABB, etc. as an independent protection unit or system expansion module.

Long life components: Industrial grade component selection, supporting 7 × 24-hour continuous operation and reducing maintenance frequency.

Application scenarios: Widely used for vibration safety protection of rotating machinery such as power plant steam turbines, petrochemical compressors, metallurgical fans, and water plant pump sets.

PROTECH SYSTEMS PBI-6SA印刷电路板 产品展示
