SANYO DENKI QS1L03LJ0YP26B伺服控制器
1.产 品 资 料 介 绍：
- 核心定位：SANYO DENKI QS1L03LJ0YP26B 是小功率伺服控制器，主打轻量化与精准控制，为同功率段伺服电机提供稳定驱动信号，适配紧凑型自动化设备的动力控制需求。
- 功率适配：从型号 “03” 推测，适配额定功率约 0.3kW 的伺服电机，适合驱动轻载部件，如微型传动模组、精密仪器执行机构、小型自动化设备驱动单元等。
- 控制模式：支持位置、速度两种基础控制模式，可通过参数灵活切换，满足轻载设备的精准定位（如元件抓取对位）与恒速运行（如低速输送）需求。
- 供电规格：预计兼容 AC 100-240V 宽电压输入，无需改造常规工业供电回路，适配不同区域车间用电环境，降低系统布线难度。
- 信号交互：支持脉冲指令输入（如脉冲 + 方向、CW/CCW），能接收 PLC 或运动控制器的控制信号，同时反馈电机运行状态（如转速、故障信号），实现基础闭环控制。
- 保护功能：具备过流、过压、欠压、过热及电机过载保护，异常时自动切断输出，避免控制器与电机因故障损坏，提升设备运行安全性。
- 适配电机：建议搭配 SANYO DENKI 同功率段小伺服电机（如 Q 系列、P 系列低功率型号），参数预设匹配，减少调试工作量，降低兼容风险。
- 结构特点：采用紧凑式设计，体积小巧，可嵌入设备控制柜狭小空间，或与电机就近安装，缩短接线距离，减少信号干扰，优化设备布局。
- 典型应用：用于电子元件组装机（如微型贴片机构）、精密检测仪器（如传感器驱动单元）、小型医疗设备（如样本处理传动）、轻载输送线（如微型零件传输）等场景。
- 使用价值：相比通用控制器，体积更小、能耗更低，且与同品牌电机适配性强，能简化轻载自动化系统集成，降低设备整体成本，同时保障驱动精度与稳定性。
SANYO DENKI QS1L03LJ0YP26B伺服控制器 英文资料：
Core positioning: SANYO DENKI QS1L03LJ0YP26B is a low-power servo controller that focuses on lightweight and precise control, providing stable driving signals for servo motors in the same frequency range and adapting to the power control needs of compact automation equipment.
Power adaptation: Based on the model "03", it is inferred that it is suitable for servo motors with a rated power of about 0.3 kW, which are suitable for driving lightweight components such as micro transmission modules, precision instrument actuators, and small automation equipment drive units.
Control mode: Supports two basic control modes, position and speed, which can be flexibly switched through parameters to meet the precise positioning (such as component grasping and alignment) and constant speed operation (such as low-speed conveying) requirements of light load equipment.
Power supply specifications: It is expected to be compatible with AC 100-240V wide voltage input, without the need to modify conventional industrial power supply circuits, suitable for different regional workshop power environments, and reduce the difficulty of system wiring.
Signal interaction: Supports pulse command input (such as pulse+direction, CW/CCW), can receive control signals from PLC or motion controller, and provide feedback on motor operation status (such as speed and fault signals), achieving basic closed-loop control.
Protection function: It has overcurrent, overvoltage, undervoltage, overheating, and motor overload protection. In case of abnormalities, it automatically cuts off the output to prevent damage to the controller and motor due to faults, and improve the safety of equipment operation.
Motor adaptation: It is recommended to pair with SANYO DENKI low power servo motors (such as Q series and P series low-power models) with preset parameters to reduce debugging workload and compatibility risks.
Structural features: Adopting a compact design with a small volume, it can be embedded in narrow spaces of equipment control cabinets or installed near motors, shortening wiring distance, reducing signal interference, and optimizing equipment layout.
Typical applications: Used in electronic component assembly machines (such as micro mount mechanisms), precision testing instruments (such as sensor drive units), small medical equipment (such as sample processing and transmission), light load conveyor lines (such as micro part transmission), and other scenarios.
Usage value: Compared with general controllers, it is smaller in size, consumes less energy, and has strong compatibility with motors of the same brand. It can simplify the integration of light load automation systems, reduce overall equipment costs, and ensure driving accuracy and stability.
SANYO DENKI QS1L03LJ0YP26B伺服控制器 产品展示
