WOODWARD 9905-970 模拟输入模块

WOODWARD 9905-970 模拟输入模块

1.产 品 资 料 介 绍：

中文资料：

WOODWARD 9905-970 模拟输入模块 是 Woodward 公司生产的一款工业级模拟信号采集模块，广泛应用于汽轮机、燃气轮机控制系统中，作为 505 系列、MicroNet 或 Atlas II 系列控制系统的扩展模块。

产品概述
该模块支持多路模拟输入信号采集，适配工业现场常用的电压和电流信号，如 0–5V、0–10V、4–20mA 等，具有高精度、抗干扰能力强、稳定性高等特点。通常作为核心控制系统中的信号输入部分，与主控制器通过背板总线通信。

主要功能

1. 采集模拟量信号，如温度、压力、位置、电流等传感器输出；

2. 提供多通道输入能力，支持 8 路或 16 路信号通道（根据具体配置）；

3. 支持信号隔离，提升系统抗干扰能力；

4. 通过背板接口与主控模块通信，无需单独供电；

5. 支持诊断功能，如信号开路、短路检测。

技术特性
– 输入类型：支持标准电流（如 4–20mA）或电压信号（如 0–10V）
– 分辨率：12 位或更高
– 隔离方式：通道与主控电路之间隔离
– 工作电压：从主控制系统供电
– 工作温度范围：-40°C 到 +70°C，适合恶劣工业环境
– 安装方式：插入式模块安装于机架中

典型应用
– 汽轮机控制系统
– 燃气轮机控制系统
– 发电机组控制
– 工业过程自动化
– 石油天然气领域的控制柜系统

英文资料：

WOODWARD 9905-970 Analog Input Module is an industrial grade analog signal acquisition module produced by Woodward, widely used in steam turbine and gas turbine control systems as an extension module for 505 series, MicroNet or Atlas II series control systems.

product overview

This module supports multi-channel analog input signal acquisition and is suitable for commonly used voltage and current signals in industrial fields, such as 0-5V, 0-10V, 4-20mA, etc. It has the characteristics of high precision, strong anti-interference ability, and high stability. Usually used as the signal input part in the core control system, it communicates with the main controller through the backplane bus.

major function

Collect analog signals, such as temperature, pressure, position, current and other sensor outputs;

Provide multi-channel input capability, supporting 8 or 16 signal channels (depending on specific configuration);

Support signal isolation to enhance the system's anti-interference capability;

Communicate with the main control module through the backplane interface without the need for separate power supply;

Support diagnostic functions such as signal open circuit and short circuit detection.

Technical Characteristics

- Input type: Supports standard current (such as 4-20mA) or voltage signal (such as 0-10V)

Resolution: 12 bits or higher

- Isolation method: Isolation between the channel and the main control circuit

- Working voltage: powered by the main control system

- Operating temperature range: -40 ° C to+70 ° C, suitable for harsh industrial environments

- Installation method: Plug in module installed in the rack

Typical applications

- Steam turbine control system

- Gas turbine control system

- Generator set control

Industrial process automation

Control cabinet system in the field of oil and gas
