Xycom XVME-085非智能内核（NIKL）原型开发模块

Xycom XVME-085非智能内核（NIKL）原型开发模块

1.产 品 资 料 介 绍：

1. 核心采用 NIKL 非智能内核设计，源自 Xycom 标准 VME I/O 模块的成熟方案，兼容性与可靠性有保障。
2. 完全兼容 VMEbus IEEE 1014 标准，支持 A16/D08 接口规格，可作为标准从设备接入 VME 背板。
3. 内置完整信号链路，涵盖时序生成、数据 / 地址 / 控制信号缓冲，满足 8/16 位从机通信需求。
4. 集成 VMEbus 中断器支持电路，可灵活配置中断请求，适配多主设备系统交互。
5. 配备跳线 / 开关可选的地址解码电路，支持自定义地址映射，提升系统地址资源利用率。
6. 提供 35.5 英寸原型布线网格，支持手工绕线与元件焊接，满足快速原型验证需求。
7. 遵循 Xycom 标准 I/O 架构，内置模块 I/O 接口、状态 / 控制寄存器及状态指示灯，便于功能调试。
8. 单槽位 6U 尺寸设计（233.35 mm × 160 mm），适配标准 VME 机箱，节省机柜空间。
9. 核心供电为 +5VDC，典型功耗 700 mA，兼容 VME 背板电源分配规范。
10. 快速响应特性：读周期总时长 535 ns，写周期总时长 665 ns，中断响应延迟低至 425 ns。
11. 工作温度 0°C 至 65°C，存储温度 -40°C 至 85°C，适应工业现场温湿度波动环境。
12. 支持热插拔操作，可在系统带电状态下安装 / 移除，降低调试对生产的影响。
13. 模块自带电气隔离设计，抑制现场电磁干扰，保障信号传输稳定性。
14. 配套 XVME-090 扩展模块可拓展功能接口，适配复杂原型开发场景。
15. 工业级封装与元器件选型，平均无故障时间长，适合连续运行的原型验证与小批量生产。

Xycom XVME-085非智能内核（NIKL）原型开发模块  英文资料：

Xycom XVME-085 is a 6U compact prototype development module based on the VMEbus standard. The core adopts the mature Non Intelligent Kernel (NIKL) architecture, providing complete signal support for 8/16 bit VME slave devices. Users can customize application circuits in the reserved prototype area to quickly verify non-standard interfaces and special functional modules.

The core adopts NIKL non intelligent core design, derived from the mature solution of Xycom standard VME I/O module, with guaranteed compatibility and reliability.

Fully compatible with the VMEbus IEEE 1014 standard, supporting A16/D08 interface specifications, and can be used as a standard to connect devices to the VME backplane.

Built in complete signal link, covering timing generation, data/address/control signal buffering, meeting 8/16 bit slave communication requirements.

The integrated VMEbus interrupt support circuit allows for flexible configuration of interrupt requests and adapts to multi master device system interaction.

Equipped with jumper/switch optional address decoding circuit, supports custom address mapping, and improves system address resource utilization.

Provide a 35.5-inch prototype wiring grid that supports manual winding and component soldering, meeting the requirements of rapid prototyping verification.

Following the Xycom standard I/O architecture, it has built-in module I/O interfaces, status/control registers, and status indicator lights for easy functional debugging.

Single slot 6U size design (233.35 mm × 160 mm), compatible with standard VME chassis, saving cabinet space.

The core power supply is+5VDC, with a typical power consumption of 700 mA, compatible with VME backplane power distribution specifications.

Quick response feature: The total read cycle time is 535 ns, the total write cycle time is 665 ns, and the interrupt response delay is as low as 425 ns.

The working temperature ranges from 0 ° C to 65 ° C, and the storage temperature ranges from -40 ° C to 85 ° C, suitable for industrial site temperature and humidity fluctuations.

Support hot plug operation, can be installed/removed while the system is powered on, reducing the impact of debugging on production.

The module comes with an electrical isolation design to suppress on-site electromagnetic interference and ensure signal transmission stability.

The supporting XVME-090 expansion module can expand functional interfaces and adapt to complex prototype development scenarios.

Industrial grade packaging and component selection, with a long average time between failures, suitable for continuous prototype validation and small batch production.

Suitable for non-standard interface development of VME bus, prototype of motion control card (such as rotary transformer interface), verification of dedicated I/O modules, and research and development of industrial automation special function modules, it is the core tool for quickly implementing customized solutions for VME bus.

Xycom XVME-085非智能内核（NIKL）原型开发模块  产品展示
