Xycom 9450屏幕监视器面板

1.产 品 资 料 介 绍：

Xycom 9450 屏幕监视器面板

核心特点

1. 14 英寸 SVGA 彩色显示面板，分辨率 1024×768，配备 Lexan 防冲击保护屏，显示清晰耐用。
2. 前面板密封达到 NEMA 4/12（IP65）标准，防尘防溅，适配油污、粉尘工业环境。
3. 集成 32 个数据输入键 + 20 个功能键，可选加装电阻式触摸屏，满足本地快速操作。
4. 兼容 IBM PC/AT 标准主板（486/5x86/Pentium 可选），7 槽无源背板，支持多种工业板卡扩展。
5. 宽范围 AC 供电（115/230VAC，50/60Hz，3.3A），适配全球工业电网，可选直流供电方案。
6. 标配 IDE 硬盘 + 软驱位，可选闪存盘（FLASH），满足程序存储与数据备份。
7. 提供 RS-232 双串口、并口、以太网、外部打印机接口，方便连接 PLC 与上位系统。
8. 支持 MS-DOS 等工业级操作系统，兼容传统工业控制软件与 SoftScreen HMI 软件。
9. 可抽出式计算机模块，三颗旋钮螺丝即可快速拆卸，大幅缩短维护停机时间。
10. 宽温工作范围（0℃~50℃，部分配置 - 10℃起），抗振动、抗电磁干扰，适应恶劣工况。
11. 支持面板安装或 19 英寸机架安装，安装方式灵活，适配不同控制室布局。
12. 内置诊断指示灯，可快速判断电源、硬盘、通信等关键状态。
13. 全金属机箱，被动散热为主，避免风扇故障导致的系统停机。
14. 符合 CE、UL 工业认证标准，具备完善的过压、过流保护设计。
15. 长期备品备件支持，适合长期运行的老旧工业控制系统升级与替换。

Xycom 9450屏幕监视器面板   英文资料：

Xycom 9450 Screen Monitor Panel

Xycom 9450 is a classic industrial grade integrated HMI screen monitor panel, adopting a PC/AT compatible architecture, integrating a 14 inch SVGA display and dedicated operation button area, designed for human-machine interaction in harsh industrial sites such as factory workshops, metallurgy, and power. It supports panel/rack installation, outstanding protection and stability.

Core Features

14 inch SVGA color display panel, resolution 1024 × 768, equipped with Lexan impact protection screen, clear and durable display.

The front panel is sealed to NEMA 4/12 (IP65) standard, dust-proof and splash proof, and suitable for industrial environments with oil stains and dust.

Integrate 32 data input keys and 20 function keys, and optionally install a resistive touch screen to meet local fast operation requirements.

Compatible with IBM PC/AT standard motherboard (486/5x86/Pentium optional), 7-slot passive backplane, and supports various industrial board expansion.

Wide range AC power supply (115/230VAC, 50/60Hz, 3.3A), compatible with global industrial power grids, with optional DC power supply solutions.

Standard IDE hard drive and floppy drive, optional flash drive (FLASH) to meet program storage and data backup needs.

Provide RS-232 dual serial port, parallel port, Ethernet, and external printer interfaces for easy connection between PLC and upper system.

Supports industrial grade operating systems such as MS-DOS, compatible with traditional industrial control software and SoftScreen HMI software.

The withdrawable computer module can be quickly disassembled with three knob screws, greatly reducing maintenance downtime.

Wide temperature working range (0 ℃~50 ℃, with some configurations starting from -10 ℃), anti vibration, anti electromagnetic interference, suitable for harsh working conditions.

Supports panel installation or 19 inch rack installation, with flexible installation methods and adaptability to different control room layouts.

Built in diagnostic indicator lights can quickly determine key status such as power, hard drive, and communication.

All metal chassis, with passive heat dissipation as the main feature, to avoid system shutdown caused by fan failure.

Compliant with CE and UL industrial certification standards, with comprehensive overvoltage and overcurrent protection design.

Long term spare parts support, suitable for upgrading and replacing old industrial control systems that operate for a long time.

Xycom 9450屏幕监视器面板   产品展示
