1336-PB-SP2B驱动电源板

1.产 品 资 料 介 绍：

1336-PB-SP2B 驱动电源板介绍

1. 属于 1336 系列变频器专用预充电控制电源板
2. 适配 460V 电压等级，60–600HP 中大功率机型
3. 兼容 1336 PLUS、PLUS II、FORCE、IMPACT、REGEN 系列
4. 核心作用：限制上电浪涌电流，保护整流桥与母线电容
5. 完成预充电后自动切换主回路，保证正常运行
6. 集成电压采样、继电器驱动、状态反馈电路
7. 板载 LED 指示灯，显示预充电状态与故障信息
8. 具备预充电超时、母线过压、欠压多重保护
9. 常见故障代码：F11 预充电故障、F22 母线欠压
10. 故障现象多为上电失败、电阻发热烧毁、电压无法建立
11. 易损部件：预充电电阻、驱动继电器、采样回路元件
12. 已原厂停产，市场以二手、翻新、库存备件为主
13. 与 SP22B、SP23B 等型号电压功率不同，不可直接互换
14. 拆装必须断电放电 10 分钟以上，做好防静电措施
15. 维修建议直接更换整板，长期可升级 PowerFlex 系列

1336-PB-SP2B驱动电源板 英文资料：

1336-PB-SP2B Driver Power Board Introduction

1336-PB-SP2B is a pre charging power board specifically designed for Allen Bradley 1336 series frequency converters. It is mainly used to control the charging of bus capacitors and ensure the safe start-up of the frequency converter. The following is a detailed introduction:

Belonging to the 1336 series inverter dedicated pre charging control power board

Suitable for 460V voltage level, 60-600HP medium and high power models

Compatible with 1336 PLUS, PLUS II, FORCE, IMPACT, REGEN series

Core function: Limit surge current during power on, protect rectifier bridge and bus capacitor

Automatically switch to the main circuit after completing pre charging to ensure normal operation

Integrated voltage sampling, relay drive, and state feedback circuit

Onboard LED indicator light, displaying pre charging status and fault information

Equipped with multiple protections for overcharging timeout, bus overvoltage, and undervoltage

Common fault codes: F11 pre charging fault, F22 bus undervoltage

The common fault phenomena are power on failure, resistance heating and burning, and inability to establish voltage

Vulnerable components: pre charging resistor, driving relay, sampling circuit components

The original factory has ceased production, and the market is dominated by second-hand, refurbished, and inventory spare parts

Different in voltage and power from models such as SP22B and SP23B, they cannot be directly interchanged

Disassembly and assembly must be powered off and discharged for at least 10 minutes, and anti-static measures must be taken

Repair suggestion: ｒｅｐｌａｃｅ the entire board directly, which can be upgraded to the PowerFlex series in the long term

In summary, 1336-PB-SP2B is a key component for the electrical safety of 1336 frequency converters. Understanding its functions and fault characteristics can quickly identify problems and complete spare parts replacement.

1336-PB-SP2B驱动电源板 产品展示
