1.产 品 资 料 介 绍：
1394C-SJT05-D 交流电驱动器（伺服系统模块）
- 产品定位：1394C 系列5kW伺服系统模块，属多轴运动控制核心单元。
- 输入规格：三相324–528V AC，50/60Hz，输入电流6.5A。
- 母线输出：380V 输入对应530V DC，460V 输入对应680V DC。
- 功率输出：连续4/5kW，峰值28kW。
- 电流输出：连续7.36A，峰值15.0A。
- 架构特性：模块化设计，单机架最多可扩展4 轴，节省布线与空间。
- 通讯方式：标配SERCOS 光纤环网，支持高速多轴同步控制。
- 控制模式：支持速度 / 转矩 / 位置闭环，兼容模拟与数字给定。
- 反馈支持：兼容差分 AB 正交编码器（最高 4MHz），支持外部全闭环反馈。
- 保护功能：过流、过压、欠压、过热、编码器故障、热过载多重保护。
- 诊断工具：板载LED 状态灯，内置数字故障与电流 / 温度监控。
- 接口配置：SCANport、DI/DO、模拟量、编码器、电机动力接口齐全。
- 应用场景：机床、半导体、包装、印刷、机器人等高精度多轴设备。
- 产品状态：原厂已停产，市场以二手、翻新、维修备件为主。
- 替代方案：升级至Kinetix 5500/6500系列伺服驱动器，适配新电机与控制器。
1394C-SJT05-D交流电驱动器 英文资料：
1394C-SJT05-D AC Driver (Servo System Module)
1394C-SJT05-D is a Rockwell Allen Bradley 1394C series 5kW modular servo drive system module used for multi axis high-precision motion control, supporting SERCOS fiber optic communication and GMC integrated architecture.
Product positioning: 1394C series 5kW servo system module, belonging to the core unit of multi axis motion control.
Input specifications: Three phase 324-528V AC, 50/60Hz, input current 6.5A.
Bus output: 380V input corresponds to 530V DC, 460V input corresponds to 680V DC.
Power output: continuous 4/5kW, peak 28kW.
Current output: continuous 7.36A, peak 15.0A.
Architecture features: Modular design, single rack can expand up to 4 axes, saving wiring and space.
Communication method: Standard SERCOS fiber ring network, supporting high-speed multi axis synchronous control.
Control mode: Supports speed/torque/position closed-loop, compatible with analog and digital settings.
Feedback support: Compatible with differential AB orthogonal encoder (up to 4MHz), supports external full closed-loop feedback.
Protection functions: multiple protections for overcurrent, overvoltage, undervoltage, overheating, encoder failure, and thermal overload.
Diagnostic tool: onboard LED status light, built-in digital fault and current/temperature monitoring.
Interface configuration: SCANPort, DI/DO, analog, encoder, and motor power interfaces are complete.
Application scenarios: high-precision multi axis equipment such as machine tools, semiconductors, packaging, printing, robots, etc.
Product status: The original factory has ceased production, and the market mainly consists of second-hand, refurbished, and repair spare parts.
Alternative solution: Upgrade to Kinetix 5500/6500 series servo drives, compatible with new motors and controllers.
In summary, 1394C-SJT05-D is the core module of the 1394C series 5kW servo system, known for its modularity, high-speed communication, and multi axis synchronization. It is a key spare part for existing precision equipment, and faults often manifest as communication abnormalities, no output, and overcurrent alarms. It is recommended to ｒｅｐｌａｃｅ the entire board or upgrade the system.
