1746-NR4电阻模拟输入

1.产 品 资 料 介 绍：

1746-NR4 电阻模拟输入模块介绍

1. 属于 SLC 500 系列 4 通道电阻与 RTD 模拟输入模块
2. 支持 Pt100、Pt1000、Ni120、Cu10 等多种 RTD 传感器
3. 可直接测量 150Ω、500Ω、1000Ω、3000Ω 电阻信号
4. 支持 2 线、3 线、4 线制接线方式，有效降低线路误差
5. 内置激励电流源与高精度 A/D 转换电路
6. 可输出摄氏度、华氏度或电阻值信号
7. 具备数字滤波功能，提升信号稳定性
8. 支持断线、短路、超量程故障检测与自校准
9. 输入与背板之间电气隔离，抗干扰能力强
10. 配备模块及通道状态 LED 指示灯
11. 占用 SLC 500 机架单个插槽，安装便捷
12. 采用可拆卸端子排，方便现场布线维护
13. 由背板电源供电，无需额外外部电源
14. 广泛应用于工业温度监测、电位计信号采集等场景
15. 该型号已停产，市场以二手、翻新备件为主

1746-NR4电阻模拟输入 英文资料：

Introduction to 1746-NR4 Resistance Analog Input Module

1746-NR4 is a dedicated 4-channel resistor/RTD analog input module for the Rockwell SLC 500 series, mainly used for temperature and resistance signal acquisition. The following is a detailed introduction:

Belonging to SLC 500 series 4-channel resistor and RTD analog input module

Supports various RTD sensors such as Pt100, Pt1000, Ni120, Cu10, etc

Can directly measure resistance signals of 150 Ω, 500 Ω, 1000 Ω, and 3000 Ω

Supports 2-wire, 3-wire, and 4-wire wiring methods, effectively reducing line errors

Built in excitation current source and high-precision A/D conversion circuit

Can output signals in Celsius, Fahrenheit, or resistance values

Equipped with digital filtering function to enhance signal stability

Support fault detection and self calibration for wire breakage, short circuit, and over range faults

Electrical isolation between input and backplane, strong anti-interference ability

Equipped with module and channel status LED indicator lights

Occupying a single slot in the SLC 500 rack, easy to install

Adopting detachable terminal blocks for convenient on-site wiring and maintenance

Powered by the backplane power supply, no additional external power is required

Widely used in industrial temperature monitoring, potentiometer signal acquisition and other scenarios

This model has been discontinued, and the market mainly consists of second-hand and refurbished spare parts

In summary, 1746-NR4 is a high-precision analog input module specifically designed for resistance and RTD temperature measurement in the SLC 500 system, suitable for various industrial equipment that requires precise temperature acquisition.
