1769-ADN适配器模块

1769-ADN适配器模块

1.产 品 资 料 介 绍：

1. 型号全称 1756-L55M23，属罗克韦尔 ControlLogix 系列，为预集成内存的完整 CPU 模块。
2. 处理器为 100 MHz PowerPC 架构，双 CPU 分工（主 CPU + 背板 CPU），运算效率高。
3. 内置1.5 MB RAM（用户程序 / 数据）+ 1.5 MB 非易失性内存，无需额外配内存卡。
4. 布尔指令执行速度0.08 µs，程序扫描快，适合高速控制场景。
5. 标配 RS-232 串口，支持 DF1、ASCII、Modbus RTU 等协议。
6. 支持 EtherNet/IP、ControlNet、DeviceNet 主流工业总线，可做 CIP 标签共享。
7. 兼容 Studio 5000（原 RSLogix 5000），支持梯形图、ST、FBD、SFC 编程。
8. 支持128 个可配置任务（周期 / 事件 / 连续），多任务调度灵活。
9. 最大 I/O 能力：数字量约 128,000 点、模拟量 4,000 入 / 2,000 出，扩展能力强。
10. 适配标准 ControlLogix 机架，支持热插拔，在线维护便捷。
11. 背板供电：5.1V DC 1.23A、24V DC 14mA，功耗约 5.7W。
12. 配 1756-BA1 电池，断电后保持 RAM 数据与实时时钟。
13. 工作温度 0–60°C，湿度 5%–95% 无凝露，工业级 EMC 与抗震设计。
14. 支持冗余架构（需 ControlNet 网络），提升系统可用性。
15. 已停产，市场以翻新 / 备件为主，适合老系统升级与维护。

1769-ADN适配器模块  英文资料：

Introduction to the Core of 1769-ADN DeviceNet Adapter Module

Model 1769-ADN belongs to the Rockwell Compact I/O series DeviceNet adapter module.

Used to connect Compact I/O modules to the DeviceNet fieldbus network.

Supports three communication rates: 125, 250, and 500 kbps.

Can serve as a DeviceNet slave module for data exchange with the master controller.

Compatible with controller platforms such as CompactLogix and MicroLogix 1500.

Supports expansion connections for up to 30 Compact I/O modules.

Using a dip switch to set the DeviceNet node address, with simple configuration.

Equipped with LED status indicator lights, convenient for module and network status diagnosis.

Provide electrical isolation for DeviceNet ports to enhance on-site anti-interference capabilities.

The power supply adopts a dual channel power supply mode of 5V DC for the backplane and 24V DC for the auxiliary.

Supports two installation methods: DIN rail installation and panel installation.

The working temperature range is 0-60 ° C, which meets the environmental requirements of industrial sites.

Compliant with industrial safety and electromagnetic compatibility certification standards such as UL and CE.

Support online replacement and hot plugging operations for easy system maintenance.

Widely used in distributed I/O, small automated production lines, and equipment renovation projects.

The above are the core technologies and application points of the 1769-ADN adapter module. The content is concise and practical, and can be directly used for product introduction and technical selection reference.
