1794-ACN15适配器模块

1.产 品 资 料 介 绍：

Allen-Bradley 1794-ACN15 适配器模块

1. 采用 ControlNet V1.5 协议，1794-ACN15 通信速率达 5Mbps，实时性强。
2. 可管理最多 8 个 Flex I/O 模块，适配 1794 系列数字量 / 模拟量 I/O。
3. 供电宽压 DC19.2-31.2V，功耗低，适配工业常用电源。
4. 单 BNC 接口，支持 RG-6 同轴电缆，布线稳定可靠。
5. 内置 75Ω 终端电阻，拨码开关启用，简化网络配置。
6. 支持生产者 / 消费者模式，多控制器共享 I/O 数据。
7. 兼容 ControlLogix、CompactLogix 等主流控制器，无缝集成。
8. 面板带 NET、MOD、FLT 等 LED 指示灯，状态一目了然。
9. 具备过压、过流保护，1794-ACN15 运行安全稳定。
10. 输出背板 5V/640mA，为本地 I/O 模块供电。
11. 抗干扰能力强，适配车间复杂电磁环境。
12. 温度适配 0°C-60°C，湿度 5%-95% 非冷凝工况。
13. 结构紧凑，导轨安装，节省控制柜空间。
14. 支持水平 / 垂直安装，现场布局灵活便捷。
15. 符合 UL、CSA、IEC 标准，工业认证齐全耐用。

1794-ACN15适配器模块  产品英文

Allen Bradley 1794-ACN15 adapter module

Allen Bradley 1794-ACN15 is a Flex I/O series ControlNet communication adapter module designed specifically for distributed I/O and is a critical interface component for industrial fieldbus systems.

Adopting the ControlNet V1.5 protocol, the 1794-ACN15 communication rate reaches 5Mbps, with strong real-time performance.

Can manage up to 8 Flex I/O modules, compatible with 1794 series digital/analog I/O.

Power supply with a wide voltage range of DC19.2-31.2V, low power consumption, suitable for commonly used industrial power sources.

Single BNC interface, supporting RG-6 coaxial cable, stable and reliable wiring.

Built in 75 Ω terminal resistor, dip switch enabled, simplifies network configuration.

Support producer/consumer mode, with multiple controllers sharing I/O data.

Compatible with mainstream controllers such as ControlLogix and CompactLogix, seamlessly integrated.

The panel is equipped with LED indicator lights such as NET, MOD, FLT, etc., making the status clear at a glance.

Equipped with overvoltage and overcurrent protection, 1794-ACN15 operates safely and stably.

Output backplane 5V/640mA to power local I/O modules.

Strong anti-interference ability, suitable for complex electromagnetic environments in workshops.

Temperature adaptation: 0 ° C-60 ° C, humidity: 5% -95%, non condensing condition.

Compact structure, rail installation, saving control cabinet space.

Support horizontal/vertical installation, flexible and convenient on-site layout.

Compliant with UL, CSA, and IEC standards, with complete and durable industrial certification.

In summary, the Allen Bradley 1794-ACN15 adapter module has stable performance, efficient communication, and easy installation, making it an ideal choice for connecting ControlNet networks in distributed I/O systems. It is widely used in automation fields such as automotive, packaging, and material handling.
