DSQC609 3HAC14178-1电源模块

1.产 品 资 料 介 绍：

ABB DSQC609 3HAC14178-1 电源模块

1. 品牌型号：ABB DSQC609，物料号 3HAC14178-1，官方名称 Power Supply Module（电源模块）。
2. 适配系统：IRC5 系列机器人控制器，兼容 IRB 120/140/2600/4600/6700 等全系列 IRC5 机型。
3. 核心功能：将外部交流输入转换为稳定 24V DC，为控制器内部核心电路供电；具备稳压、滤波、多重保护与状态监测。
4. 电气规格：
   • 输入：100–240V AC，50/60Hz，宽电压兼容
   • 输出：24V DC，额定电流 2A，最大功率 48W
   • 效率：≥90%，低发热、低功耗
5. 保护功能：内置过压、欠压、过载、短路、过热保护，保障内部电路安全。
6. 状态指示：板载 LED 指示灯，显示电源正常、故障、输出状态，便于快速诊断。
7. 安装方式：IRC5 控制器内部背板插槽直插安装，模块化设计，支持快速更换。
8. 物理参数：尺寸约 84.6×48×17.5mm，净重 0.3kg，防护等级 IP20。
9. 环境适应：工作温度 - 20℃~+55℃，湿度 5%–95%（无冷凝），抗工业电磁干扰。
10. 认证标准：通过 CE、UL、CSA 安全认证，符合工业设备安全规范。
11. 产品状态：IRC5 系统标配核心电源模块，目前仍在产，为常用备件。
12. 应用场景：IRC5 控制器内部供电、CPU / 轴计算机 / 通信板 / I/O 模块供电、机器人控制系统基础电源保障。

DSQC609 3HAC14178-1电源模块 英文资料：

ABB DSQC609 3HAC14178-1 power module

DSQC609 (3HAC14178-1, also known as PBSE5117) is a specialized 24V DC power module for ABB IRC5 series robots. It provides stable power supply for the core components of the controller (CPU, axis computer, communication board, I/O module) and is the basic power supply unit of the IRC5 control system.

Brand and model: ABB DSQC609, material number 3HAC14178-1, official name Power Supply Module.

Adaptation system: IRC5 series robot controller, compatible with all IRC5 models including IRB 120/140/2600/4600/6700.

Core function: Convert external AC input into stable 24V DC to power the internal core circuit of the controller; Equipped with voltage stabilization, filtering, multiple protections, and status monitoring.

Electrical specifications:

Input: 100-240V AC, 50/60Hz, wide voltage compatible

Output: 24V DC, rated current 2A, maximum power 48W

Efficiency: ≥ 90%, low heat generation, low power consumption

Protection function: Built in overvoltage, undervoltage, overload, short circuit, and overheating protection to ensure the safety of internal circuits.

Status indication: Onboard LED indicator light, displaying power supply normal, fault, and output status for quick diagnosis.

Installation method: IRC5 controller internal backplane slot direct insertion installation, modular design, supports quick replacement.

Physical parameters: size approximately 84.6 × 48 × 17.5mm, net weight 0.3kg, protection level IP20.

Environmental adaptation: Working temperature -20 ℃~+55 ℃, humidity 5% -95% (non condensing), resistant to industrial electromagnetic interference.

Certification standards: Passed CE, UL, CSA safety certifications, in compliance with industrial equipment safety regulations.

Product status: The IRC5 system comes standard with a core power module, which is still in production and is a commonly used spare part.

Application scenarios: Internal power supply for IRC5 controller, power supply for CPU/axis computer/communication board/I/O module, basic power supply guarantee for robot control system.

This module has the core advantages of wide voltage compatibility, high efficiency and stability, multiple protections, compact size, and easy installation, and is a key basic component for the stable operation of ABB IRC5 robot control system.
