1MRK000508-BDr03控制板

 ABB 1MRK000508-BDr03控制板

1.产 品 资 料 介 绍：

中文资料：

产品名称：ABB 1MRK000508-BDr03 控制板

产品类型：控制板 / 控制模块（Control Board）
制造商：ABB
典型应用系统：继电保护与控制装置（如：REF、RET、REL 系列）

一、主要功能

1. 信号处理与逻辑控制

   • 用于处理采样信号（如电压、电流）并执行逻辑控制任务，如跳闸、闭锁、告警等。

2. 控制指令执行

   • 接收来自上位机或保护程序的命令，并对断路器、开关或其他执行器发出控制指令。

3. 通信与数据交换

   • 与系统主控模块、通信接口或远动装置进行数据交互。

4. 系统状态监控与反馈

   • 实时采集设备运行状态并向主系统反馈运行参数或故障信号。

二、应用领域

1. 数字变电站自动化系统（SAS）

   • 作为继电保护装置的核心控制单元之一，用于监测和执行保护逻辑。

2. 保护与控制装置（IED）内部模块

   • 安装于 ABB 的如 REL670、RET670、REF615 等设备内部，作为主控逻辑处理单元。

3. 输电/配电系统保护应用

   • 用于110kV、220kV等高压输电系统的保护与控制系统中。

4. 过程控制与开关命令管理

   • 参与过程控制闭环中的决策执行，例如跳闸逻辑判断、故障处理等。

三、技术特点（常规）

• 支持多输入多输出逻辑控制

• 工业级电路板，抗干扰能力强，适合高压环境使用

• 模块化结构，便于设备组装与维护更换

• 支持与ABB主系统通信协议（如IEC 61850）

• 稳定性高，适合长时间连续运行

英文资料：

Product Name: ABB 1MRK000508-BDr03 Control Board

Product Type: Control Board/Control Module

Manufacturer: ABB

Typical application systems: Relay protection and control devices (such as REF, RET, REL series)

1、 Main functions

Signal Processing and Logic Control

Used to process sampling signals (such as voltage, current) and perform logic control tasks, such as tripping, locking, alarm, etc.

Control instruction execution

Receive commands from the upper computer or protection program, and issue control instructions to circuit breakers, switches, or other actuators.

Communication and Data Exchange

Interact data with the system's main control module, communication interface, or remote control device.

System status monitoring and feedback

Real time collection of device operating status and feedback of operating parameters or fault signals to the main system.

2、 Application Fields

Digital Substation Automation System (SAS)

As one of the core control units of relay protection devices, it is used to monitor and execute protection logic.

Internal modules of protection and control devices (IEDs)

Installed inside ABB devices such as REL670, RET670, REF615, etc., as the main control logic processing unit.

Application of transmission/distribution system protection

Used in the protection and control systems of high-voltage transmission systems such as 110kV and 220kV.

Process control and switch command management

Participate in decision execution in the process control loop, such as trip logic judgment, fault handling, etc.

3、 Technical characteristics (conventional)

Support multi input multi output logic control

Industrial grade circuit board with strong anti-interference ability, suitable for use in high-voltage environments

Modular structure, easy to assemble, maintain and ｒｅｐｌａｃｅ equipment

Support communication protocols with ABB main systems (such as IEC 61850)

High stability, suitable for long-term continuous operation
