ABB 1MRK000614-ABr02控制板
1.产 品 资 料 介 绍：
中文资料：
产品名称：ABB 1MRK000614-ABr02 控制板
类型：控制板 / 控制逻辑单元
制造商：ABB
应用设备：ABB 继电保护与自动化系统（如 REL、RET、REF 系列）
一、产品功能概述
控制逻辑执行单元
用于执行设备内部预设的逻辑判断、动作命令、跳闸/闭锁策略等。
信号采集与处理
对电流、电压、频率等模拟量或开关量进行实时采样和分析。
与其他功能板通信交互
与电源板、通信板、人机界面板等其他模块协同工作，实现完整控制流程。
数据监控与状态反馈
监测设备运行状态，输出告警、事件、动作记录信息至系统平台或 SCADA。
二、典型应用领域
数字化继电保护装置
应用于 ABB 的继电保护系列（如 REL670、REF615、RET670 等）中，是关键控制模块之一。
变电站自动化系统
安装于110kV~500kV 等高压变电站中的控制屏、保护屏中，用于电网保护与切换控制。
发电厂与配电系统
支持发电设备与母线系统的保护与状态切换逻辑控制。
SCADA 与远动系统接口
与通信模块联动，实现远程监控、控制命令的本地响应。
三、产品技术特性（典型）
高速微处理器逻辑控制
多路信号输入输出支持
支持电磁兼容（EMC）标准，适应严苛电力环境
插拔式模块结构，便于维修更换
支持通信协议如 IEC 61850、Modbus、DNP3 等（视主设备配置）
英文资料：
Product Name: ABB 1MRK000614-ABr02 Control Board
Type: Control Board/Control Logic Unit
Manufacturer: ABB
Application equipment: ABB relay protection and automation systems (such as REL, RET, REF series)
1、 Product Function Overview
Control logic execution unit
Used to execute preset logic judgments, action commands, trip/lockout strategies, etc. within the device.
Signal acquisition and processing
Real time sampling and analysis of analog or switch quantities such as current, voltage, frequency, etc.
Communicate and interact with other functional boards
Collaborate with other modules such as power board, communication board, human-machine interface panel, etc. to achieve a complete control process.
Data monitoring and status feedback
Monitor the operating status of the equipment, output alarm, event, and action record information to the system platform or SCADA.
2、 Typical application areas
Digital relay protection device
Applied in ABB's relay protection series (such as REL670, REF615, RET670, etc.), it is one of the key control modules.
Substation automation system
Installed in control and protection screens of high-voltage substations ranging from 110kV to 500kV, used for power grid protection and switching control.
Power plants and distribution systems
Support the protection and status switching logic control of power generation equipment and busbar systems.
SCADA and Remote Control System Interface
Integrate with the communication module to achieve local response to remote monitoring and control commands.
3、 Product Technical Characteristics (Typical)
High speed microprocessor logic control
Multi channel signal input and output support
Supports electromagnetic compatibility (EMC) standards and adapts to harsh power environments
Plug in module structure for easy maintenance and replacement
Support communication protocols such as IEC 61850, Modbus, DNP3, etc. (depending on the configuration of the main device)
